This model is discontinued
AirTAC has phased out the ACP series. You can still order this code here: we ship the current replacement ACE100X150SB, the same code under the new prefix. The ACE replacement is a current-production ISO 21287 compact cylinder in the same bore, stroke and force class, with a matching short body and the same mounting-accessory family, so it fits the same envelope. Confirm mounting-interface dimensions against the ACE datasheet before ordering.
Airtac ACP Compact Cylinder ACP100X150SB
The AirTAC ACP Compact Cylinder ACP100X150SB is a double acting DIN-standard tight/compact air cylinder with a Ø100mm bore and 150mm stroke, 1/4" air ports and a hard-anodized aluminium body. This model is discontinued — the current-production replacement is the ACE100X150SB (ISO 21287 ACE), in the same bore, stroke and force class.
- BoreØ100 mm
- Stroke150 mm
- Port size1/4"
- Acting typeDouble acting
- Rod threadM16×1.5
- StatusDiscontinued → ACE100X150SB
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac ACP Compact Cylinder ACP100X150SB
A double acting compact cylinder in the DIN-standard ACP series, the ACP100X150SB pairs a 100 mm bore with a 150 mm stroke and a 25 mm hard-chrome S45C rod on a male thread (B code). At 0.5 MPa it pushes 3927 N and pulls 3681.6 N; at 0.7 MPa push rises to 5497.8 N, with a theoretical peak of 800.9 kgf at 1.0 MPa. The hard-anodized aluminium body keeps the mounting length roughly 50% shorter than an ISO 15552 profile cylinder, so it slots into heavy press fixtures and gantries where a full-length body will not fit. This model carries the optional -S magnet, so CMSE or DMSE reed and solid-state switches can be fitted for end-position sensing.
Air supply runs 0.15-1.0 MPa (22-145 psi) with 1.5 MPa (215 psi) proof pressure, speed spans 30-500 mm/s, and fixed TPU bumpers at both ends absorb end-of-travel impact. Note that this ACP model is discontinued: the current-production replacement is ACE100X150, a direct successor in the same bore, stroke and force class - confirm the ISO 21287 mounting dimensions before swapping.
Airtac ACP Compact Cylinder ACP100X150SB Technical Specifications
| Model | Airtac ACP Compact Cylinder ACP100X150SB |
|---|---|
| Series | ACP DIN compact cylinder (discontinued) |
| Replacement | ACE100X150SB |
| Bore size | Ø100 mm |
| Stroke | 150 mm |
| Acting type | Double acting |
| Port size | 1/4" |
| Rod thread | M16×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed bumper (both ends) |
| Max standard stroke | Up to 300 mm |
Specifications follow the official AirTAC ACP datasheet (now discontinued). The ACE100X150SB (ISO 21287) carries the same bore/stroke/force class; confirm mounting-interface dimensions against the ACE datasheet before installation. Rod type: female thread (blank) or male thread (B). Thread options: PT (blank) / G.
Theoretical Output Force (Ø100mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 3927 N | 3682 N |
| 0.7 MPa | 5498 N | 5154 N |
| Max (@1.0 MPa) | 801 kgf | |
The ACE100X150SB produces the same force from the same bore. Actual usable force is lower than theoretical; size with a margin.
Model Code: Airtac ACP Compact Cylinder ACP100X150SB
| ACP | DIN compact cylinder (double-acting, discontinued). |
|---|---|
| 100 | Bore size in mm. |
| ×150 | Stroke length in mm. |
| S | Optional built-in magnet for sensor position sensing (omit for no magnet). |
| B | Rod type: B = male thread; blank = female thread. |
Replacement mapping (swap P for E): ACP→ACE, ASP→ASE, ATP→ATE, ACPD→ACED, ACPJ→ACEJ. ACP-family: ACP (double acting), ASP / ATP (single acting push / pull), ACPD (double rod), ACPJ (double rod, adjustable stroke).
Where the Airtac ACP Compact Cylinder ACP100X150SB Is Used
Pneumatic press fixture
The 3927 N push at 0.5 MPa gives a 100 mm bore stamping or marking station enough force for light forming on aluminium brackets, with the 150 mm stroke clearing the part for manual loading.
Clamping gantry in a machining cell
The short body, about 50% shorter in mounting length than an ISO 15552 profile cylinder, fits inside a CNC machine gantry to clamp or eject cast housings at up to 5497.8 N push at 0.7 MPa.
Replacing the Airtac ACP Compact Cylinder ACP100X150SB with the ACE100X150SB
At this force class, size down to ACP80X150 (2513 N push at 0.5 MPa) if the load is under about 150 kg, or stay at bore 100 when you need the full 3927 N. Remember the piston drifts when air is lost - add a rod lock or pilot check valve if the load must stay put. The male rod thread (B) suits I/Y knuckles, and FA/FB flange, LB foot or CA/CB clevis mounts bolt to the same face. Since ACP100X150SB is discontinued, order ACE100X150 and verify the ISO 21287 footprint against your fixture.
Replacement checklist
- ✓ Current-production ACE → ACE100X150SB
- ✓ Same bore / stroke / force class
- ✓ Confirm ISO 21287 mounting dimensions
- ✓ Port/thread type (PT / G)
- ✓ Add -S for magnet if you need sensors
Airtac ACP Compact Cylinder ACP100X150SB FAQ
At 0.5 MPa it pushes 3927 N and pulls 3681.6 N; at 0.7 MPa push is 5497.8 N and pull 5154.2 N; theoretical maximum is 800.9 kgf at 1.0 MPa. It is double acting with a 25 mm male-thread rod, 1/4" PT ports, 0.15-1.0 MPa (22-145 psi) operating pressure and 30-500 mm/s speed. The model is discontinued - ACE100X150 is the current replacement.
The hard-anodized aluminium body follows the DIN-standard compact layout, saving roughly 50% of the mounting length of an ISO 15552 profile cylinder, with FA/FB flange, LB foot and CA/CB clevis options. The S in ACP100X150SB means the optional -S magnet is fitted, so CMSE or DMSE reed or solid-state switches can be mounted for position feedback. Fixed TPU bumpers at both ends soften end-of-travel impact.
