Airtac Adjustable Cylinder SAIJ32 SAIJ32X10-10
The AirTAC Airtac Adjustable Cylinder SAIJ32 SAIJ32X10-10 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø32mm bore and 10mm stroke, G1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ32 mm
- Stroke10 mm
- Port sizeG1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
About the Airtac Adjustable Cylinder SAIJ32 SAIJ32X10-10
The AirTAC SAIJ32X10-10 is a double-acting ISO 15552 profile cylinder featuring a rear-mounted stroke adjuster. It provides a nominal 10 mm travel that can be fine-tuned down to a 0-10 mm usable window, allowing precise end-position calibration during commissioning without adding external stops. Operating at 0.15-1.0 MPa, it delivers 402 N of push force and 345 N of pull force at 0.5 MPa.
This 32 mm bore profile cylinder uses a G1/8 port and a 12 mm carbon steel rod with an M10x1.25 thread. It includes variable air cushions at both ends to decelerate the travel, but the rear adjuster acts strictly as a stop and does not hold the load without live air pressure. The extruded aluminum barrel features sensor grooves on both sides for CMSE or DMSE switches, though this specific SKU is configured without a magnet.
Airtac Adjustable Cylinder SAIJ32 SAIJ32X10-10 Technical Specifications
| Model | Airtac Adjustable Cylinder SAIJ32 SAIJ32X10-10 |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 10 mm |
| Acting type | Double acting |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac Adjustable Cylinder SAIJ32 SAIJ32X10-10
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 32 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac Adjustable Cylinder SAIJ32 SAIJ32X10-10 Is Used
Precision End-Stop Tuning
Dial in the exact 0-10 mm travel window during machine commissioning to perfect part positioning without swapping cylinders.
Product Size Changeovers
Quickly adjust the rear stopper to accommodate slightly different product lengths on a packaging line.
Short-Stroke Clamping
Apply up to 402 N of push force at 0.5 MPa for precise, short-stroke clamping tasks in assembly fixtures.
Is the Airtac Adjustable Cylinder SAIJ32 SAIJ32X10-10 the Right Cylinder?
Choose this 32 mm bore cylinder when your application requires 402 N of push force at 0.5 MPa. If your process needs less force, stepping down to a 25 mm bore (confirm from datasheet) might suffice, while a 40 mm bore provides 628 N for heavier loads. The adjustable stroke is ideal for machine setups requiring variable end-stops or product-size changeovers, offering a distinct advantage over a fixed-stroke SAI cylinder.
As a true ISO 15552 profile cylinder, it is dimensionally interchangeable with other ISO 15552 cylinders. This model uses a PT tapered port thread and supports a reduced mounting set including Basic, FA, LB, TC, FTC, TCM1, and TCM2. Because the stroke is only 10 mm, side-load risks are minimal, but always verify alignment. For load-holding without live air, select a SAIL or BSAI cylinder instead, as this adjuster is not a lock.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac Adjustable Cylinder SAIJ32 SAIJ32X10-10 FAQ
The rear adjusting screw acts as a mechanical stopper, allowing you to trim the effective stroke back from 10 mm down to 0 mm. This provides a 0-10 mm usable travel window for fine-tuning the end position at commissioning. The adjuster is a travel stop, not a lock, and does not hold the load without live air pressure.
At 0.5 MPa, the SAIJ32X10-10 provides 402 N of push force and 345 N of pull force. It operates at speeds ranging from 30 to 800 mm/s and uses a G1/8 port for air supply.
