Airtac Adjustable Cylinder SAIJ32 SAIJ32X100-40S
The AirTAC Airtac Adjustable Cylinder SAIJ32 SAIJ32X100-40S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø32mm bore and 100mm stroke, G1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ32 mm
- Stroke100 mm
- Port sizeG1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
About the Airtac Adjustable Cylinder SAIJ32 SAIJ32X100-40S
The AirTAC SAIJ32X100-40-S is a double-acting, single-rod ISO 15552 profile cylinder featuring a rear stroke adjuster. Equipped with a magnet for position sensing, it operates reliably with CMSE reed and DMSE electronic solid-state switches. The carbon steel piston rod and PT tapered port threads ensure robust performance for standard pneumatic setups.
This model provides a 60-100 mm usable travel window by allowing you to trim the 100 mm nominal stroke back by up to 40 mm. Delivering 402 N of push force at 0.5 MPa, it utilizes a 27 mm air cushion at both ends to decelerate the load smoothly. The rear adjuster acts purely as a mechanical stop to fine-tune the end position, meaning it cannot hold a load without continuous live air pressure.
Airtac Adjustable Cylinder SAIJ32 SAIJ32X100-40S Technical Specifications
| Model | Airtac Adjustable Cylinder SAIJ32 SAIJ32X100-40S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac Adjustable Cylinder SAIJ32 SAIJ32X100-40S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 32 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac Adjustable Cylinder SAIJ32 SAIJ32X100-40S Is Used
Machine Changeovers
Quickly adapt the 60-100 mm travel window during product size transitions on a packaging line without disassembling the cylinder mounting.
Variable End Stops
Fine-tune the retract position at commissioning using the rear screw, perfect for testing different sensor trigger points on a prototype.
Light-Duty Positioning
Move small jigs with 402 N of force at 0.5 MPa, relying on the external stopper to set the exact resting coordinates for a delicate assembly process.
Is the Airtac Adjustable Cylinder SAIJ32 SAIJ32X100-40S the Right Cylinder?
Choose this 32 mm bore cylinder when your application requires 402 N of push force at 0.5 MPa and precise end-position tuning without swapping hardware. The adjustable stroke is ideal for machine changeovers, allowing you to dial in the travel window quickly. If you need to step up to 628 N of push force, consider the 40 mm bore neighbor. Since this is a 100 mm stroke, side-loading is minimal, but always ensure axial alignment. For applications requiring true load-holding without live air, select the SAIL (air-released lock) or BSAI (clamp-lock) series instead, as the SAIJ rear stopper is not a brake. To match this ISO 15552 footprint exactly, specify the 32 mm bore, 100 mm stroke, 40 mm adjustment, PT port, and -S magnet.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac Adjustable Cylinder SAIJ32 SAIJ32X100-40S FAQ
It features a rear adjusting screw that lets you shorten the effective travel from the 100 mm nominal stroke down by up to 40 mm, creating a 60-100 mm usable window. The adjuster acts as a mechanical stop and does not lock the load without live air pressure.
It provides 402 N of push force and 345 N of pull force at 0.5 MPa, reaching up to 724 N push at 0.9 MPa. The operating speed ranges from 30 to 800 mm/s.
