AirTAC SAI Series · ISO 15552 Cylinder

Airtac Adjustable Cylinder SAIJ32 SAIJ32X100-75

The AirTAC Adjustable Cylinder SAIJ32 SAIJ32X100-75 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø32mm bore and 100mm stroke, G1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ32 mm
  • Stroke100 mm
  • Port sizeG1/8
  • Acting typeDouble acting
  • Rod threadM10×1.25
  • CushionAdjustable, 27 mm
$63.24 $70.74Save 10% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SAIJ32 stroke, mounting and version on one page All SAIJ32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac Adjustable Cylinder SAIJ32 SAIJ32X100-75

The AirTAC SAIJ32X100-75 is a double-acting ISO 15552 profile cylinder featuring a rear stroke adjuster that allows you to trim the nominal 100 mm travel back by up to 75 mm, creating a wide 25-100 mm usable window. This is ideal for machines requiring highly variable end-stops without swapping hardware.

Unlike a fixed-stroke SAI, this model lets you dial in the exact end position during commissioning. The rear screw acts purely as a mechanical stop to set the retract position, meaning it will not hold the load if air pressure drops. The extruded aluminum barrel includes sensor grooves on both sides for straightforward switch mounting.

Airtac Adjustable Cylinder SAIJ32 SAIJ32X100-75 Technical Specifications

ModelAirtac Adjustable Cylinder SAIJ32 SAIJ32X100-75
SeriesSAI ISO 15552 profile cylinder
Bore sizeØ32 mm
Stroke100 mm
Acting typeDouble acting
Port sizeG1/8
Rod threadM10×1.25
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 800 mm/s
CushionAdjustable, 27 mm
Max strokeUp to 1000 mm

Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.

Theoretical Output Force (Ø32mm)

PressurePush forcePull force
0.5 MPa346 N346 N
0.7 MPa484 N—
Max (@1.0 MPa)70 kgf

Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac Adjustable Cylinder SAIJ32 SAIJ32X100-75

SAIISO 15552 profile-barrel cylinder series.
32Bore size in mm.
×100Stroke length in mm.
-SOptional built-in magnet for sensor position sensing.

Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.

Where the Airtac Adjustable Cylinder SAIJ32 SAIJ32X100-75 Is Used

tune

Variable End-Stop Positioning

Dial in the exact retract distance between 25 and 100 mm during machine commissioning to accommodate different material thicknesses without adding external dead stops.

settings_input_component

Product Size Changeovers

Quickly reconfigure assembly line strokes for new product runs by turning the rear adjuster screw, avoiding the need to physically unbolt and replace the entire cylinder.

precision_manufacturing

Light-Duty Clamping

Apply up to 402 N of clamping force at 0.5 MPa while fine-tuning the exact clamping depth to prevent damaging delicate components.

Is the Airtac Adjustable Cylinder SAIJ32 SAIJ32X100-75 the Right Cylinder?

If you need less adjustability, a standard SAI32X100 fixed-stroke cylinder is simpler, but this SAIJ variant excels in product changeovers.

Because the 75 mm adjustment is significant relative to the 100 mm stroke, ensure your external guide rails manage side loads, as the 12 mm rod cannot absorb high lateral forces. This SAIJ32X100-75 uses a PT tapered port thread, lacks a standard magnet for sensors, and supports a reduced mounting set of Basic, FA, LB, TC, FTC, TCM1, and TCM2. It is dimensionally interchangeable per ISO 15552.

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/NPT/G)
  • ✓ Magnet (-S) for sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
  • check Installation by qualified personnel per AirTAC docs.

Airtac Adjustable Cylinder SAIJ32 SAIJ32X100-75 FAQ

The rear adjuster screw lets you mechanically shorten the retract stroke by up to 75 mm from the 100 mm nominal length, providing an effective travel window of 25 to 100 mm. It functions as a physical stop to set the end position and does not lock the load without live air pressure.

The standard speed range for this bore size is 30-800 mm/s, operating with a G1/8 port.
