Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-10
The AirTAC Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-10 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø32mm bore and 1000mm stroke, G1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ32 mm
- Stroke1000 mm
- Port sizeG1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
About the Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-10
The AirTAC SAIJ32X1000-10 is a double-acting, single-rod ISO 15552 profile cylinder featuring a rear-mounted stroke adjuster. It provides a 990 to 1000 mm usable travel window, allowing you to dial in the exact retract end-position during commissioning without adding external stops. At 0.5 MPa, it generates 402 N of push force and 345 N of pull force.
This model uses a standard carbon steel piston rod with an M10x1.25 thread and a PT tapered port. The extruded aluminum barrel includes sensor grooves on both sides for CMSE or DMSE switches, though this specific SKU is configured without a magnet. It relies on variable air cushions at both ends to decelerate the load over the long 1000 mm travel.
Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-10 Technical Specifications
| Model | Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-10 |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-10
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 32 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-10 Is Used
Long-Stroke Positioning
Fine-tune the 990-1000 mm retract position precisely during machine commissioning to ensure perfect alignment of long-travel actuators.
Product Changeover
Quickly adjust the end-stop by up to 10 mm to accommodate slight variations in product dimensions without swapping the cylinder.
Material Handling
Ideal for long-stroke sorting gates where a 402 N push force and a precisely tuned end-position prevent overshoot during transit.
Is the Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-10 the Right Cylinder?
Choose this 32 mm bore when you need precise end-position tuning over a long 1000 mm stroke and moderate force (402 N push at 0.5 MPa). If your application requires significantly more thrust, stepping up to the 40 mm bore yields 628 N of push force. The adjustable rear stopper is ideal for machine setups requiring variable end-stops, whereas a fixed SAI cylinder is better for rigid, unchanging travel limits.
Because this cylinder spans 1000 mm, the 12 mm rod requires external guiding to prevent excessive side-loading and binding. The rear adjuster acts strictly as a travel stop and does not hold the load without live air; for true load-holding, consider an AirTAC SAIL or BSAI cylinder. Mounting options are limited to Basic, FA, LB, TC, FTC, TCM1, and TCM2, omitting FB and CA styles.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-10 FAQ
At 0.5 MPa operating pressure, this 32 mm bore cylinder provides 402 N of push force and 345 N of pull force. At 0.7 MPa, the push force increases to 563 N.
The rear adjuster screw allows you to shorten the 1000 mm nominal stroke by up to 10 mm, creating a 990-1000 mm travel window. This stopper fine-tunes the end position but does not lock the load without continuous air pressure.
