Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-100
The AirTAC Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-100 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø32mm bore and 1000mm stroke, G1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ32 mm
- Stroke1000 mm
- Port sizeG1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
About the Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-100
The AirTAC SAIJ32X1000-100 is a double-acting ISO 15552 profile cylinder featuring a rear stroke adjuster that creates a 900-1000mm usable travel window from its 1000mm nominal stroke. Delivering 402N of push force at 0.5 MPa, it uses a G1/8 port and a 12mm carbon steel rod. This adjustable design allows you to fine-tune the retract end position at commissioning without adding external stops.
Because the 1000mm stroke is long relative to the 32mm bore, the 12mm rod and M10x1.25 thread require external guidance to prevent excessive side-loading. The rear adjuster acts purely as a travel stop for deceleration alongside the standard air cushions, meaning it will not hold the load without live air pressure. For position holding, consider the SAIL or BSAI series.
Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-100 Technical Specifications
| Model | Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-100 |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-100
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 32 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-100 Is Used
Variable End-Stop Tuning
Dial in the exact retract position within the 900-1000mm range during commissioning without swapping cylinders or adding external mechanical stops.
Product Size Changeover
Quickly adjust the travel limit to accommodate different package lengths on a packaging line, maximizing flexibility.
Long-Stroke Machine Setup
Fine-tune the end position on extended 1000mm travel axes, ensuring precise alignment without relying on rigid fixed strokes.
Is the Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-100 the Right Cylinder?
Choose this adjustable model over a fixed SAI when your machine setup requires variable end-stops or product-size changeovers on a 1000mm stroke. If your application needs more thrust, stepping up to a 40mm bore provides 628N at 0.5 MPa. To match this ISO 15552 replacement exactly, specify the 32mm bore, 1000mm stroke, 100mm adjustment, PT port thread, and no magnet. Mounting options include Basic, FA, LB, TC, FTC, TCM1, and TCM2.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-100 FAQ
It delivers 402N of push force and 345N of pull force at 0.5 MPa, reaching a maximum of 82 kgf at 1.0 MPa.
The rear adjuster allows you to shorten the effective stroke by up to 100mm, providing a usable travel window of 900 to 1000mm. It acts as a stop and does not lock the load without air pressure.
