Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-10S
The AirTAC Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-10S is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø32mm bore and 1000mm stroke, G1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ32 mm
- Stroke1000 mm
- Port sizeG1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
About the Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-10S
The AirTAC SAIJ32X1000-10-S is a double-acting, single-rod ISO 15552 profile cylinder equipped with a rear stroke adjuster. It delivers a 402 Newton pull force at 0.5 MPa and features a 12 mm carbon steel piston rod with an M10x1.25 thread. The built-in adjustment mechanism provides a usable travel window of 990 to 1000 mm, allowing you to dial back the nominal stroke by up to 10 mm during machine commissioning.
This variant includes a magnetic piston for position sensing with CMSE reed and DMSE electronic switches. It features variable air cushions at both ends to decelerate the payload, but the rear adjuster acts only as a mechanical stop, not a lock. For load-holding without live air pressure, consider the SAIL or BSAI series instead.
Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-10S Technical Specifications
| Model | Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-10S |
|---|---|
| Series | SAI ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | G1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-10S
| SAI | ISO 15552 profile-barrel cylinder series. |
|---|---|
| 32 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.
Where the Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-10S Is Used
Long-Stroke Conveying
Pushes or retracts diverters on a conveyor line over a 1000 mm distance, using the 10 mm rear adjuster to perfectly set the retracted position without moving the cylinder mount.
Machine Setup & Changeover
Allows operators to fine-tune the end-of-stroke position during machine format changes, trimming up to 10 mm off the travel to accommodate slightly different product lengths.
Variable End-Stop Positioning
Provides a 990 to 1000 mm adjustable travel window for assembly stations that require precise mechanical stops rather than relying solely on pneumatic cushions for final positioning.
Is the Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-10S the Right Cylinder?
Choose this 32 mm bore cylinder when an application requires 402 Newtons of pull force at 0.5 MPa and exact end-position tuning over a long 1000 mm stroke. If your process demands greater thrust, stepping up to the 40 mm bore yields 528 Newtons of pull force at the same pressure. The 10 mm adjustment window is ideal for fine-tuning variable end stops during product changeover without adding external stopper blocks.
Because the stroke reaches 1000 mm, the unsupported 12 mm rod is susceptible to deflection and side-loading; an external guide rail is strongly recommended to prevent premature seal wear. This -S magnetic model is dimensionally interchangeable per ISO 15552 and supports a reduced mounting set of Basic, FA, LB, TC, FTC, TCM1, and TCM2 (omitting FB, CA, CB, and CR). Porting is via a PT tapered G1/8 thread.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-10S FAQ
At 0.5 MPa operating pressure, this 32 mm bore cylinder provides 402 Newtons of push force and 345 Newtons of pull force. At its maximum 1.0 MPa pressure, it delivers 82 kgf of thrust.
The rear external adjusting screw lets you mechanically shorten the effective stroke by up to 10 mm, creating a 990 to 1000 mm usable travel window. It acts as a physical stop to fine-tune the retract position and does not lock the load without live air pressure.
