AirTAC SAI Series · ISO 15552 Cylinder

Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-20

The AirTAC Adjustable Cylinder SAIJ32 SAIJ32X1000-20 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø32mm bore and 1000mm stroke, G1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ32 mm
  • Stroke1000 mm
  • Port sizeG1/8
  • Acting typeDouble acting
  • Rod threadM10×1.25
  • CushionAdjustable, 27 mm
$143.27 $150.77Save 4% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SAIJ32 stroke, mounting and version on one page All SAIJ32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-20

The AirTAC SAIJ32X1000-20 is a double-acting ISO 15552 profile cylinder equipped with a rear stroke adjuster, allowing you to dial back the nominal 1000 mm travel to a precise 980-1000 mm window.

Instead of fabricating external stopper blocks to fine-tune machine timing, the integrated rear screw lets you set the retract end-position during commissioning. The extruded aluminum barrel includes sensor grooves on both sides, and while this specific SKU lacks a magnet, the design accommodates AirTAC CMSE reed and DMSE electronic switches when position feedback is needed.

Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-20 Technical Specifications

ModelAirtac Adjustable Cylinder SAIJ32 SAIJ32X1000-20
SeriesSAI ISO 15552 profile cylinder
Bore sizeØ32 mm
Stroke1000 mm
Acting typeDouble acting
Port sizeG1/8
Rod threadM10×1.25
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 800 mm/s
CushionAdjustable, 27 mm
Max strokeUp to 1000 mm

Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.

Theoretical Output Force (Ø32mm)

PressurePush forcePull force
0.5 MPa346 N346 N
0.7 MPa484 N—
Max (@1.0 MPa)70 kgf

Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-20

SAIISO 15552 profile-barrel cylinder series.
32Bore size in mm.
×1000Stroke length in mm.
-SOptional built-in magnet for sensor position sensing.

Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.

Where the Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-20 Is Used

settings_input_component

Machine Setup Tuning

Dial in the exact 980-1000 mm retract position during line commissioning without machining custom external stoppers.

conveyor_belt

Product Changeover

Quickly adapt the end-of-stroke position on a packaging conveyor when handling slightly different carton sizes.

tune

Precision End-Stop

Fine-tune the travel limit on long-stroke assemblies to synchronize timing across multiple pneumatic axes.

Is the Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-20 the Right Cylinder?

If your setup needs more thrust, stepping up to the 40 mm bore yields 628 N at the same pressure. The adjustable stroke is ideal for product changeovers where the exact end-of-travel position varies slightly, saving you from swapping out a fixed-stroke SAI cylinder.

Because the stroke extends to 1000 mm, an external guide is highly recommended to prevent excessive rod side-loading on the M10x1.25 thread. Remember that the rear adjuster functions strictly as a travel stop and does not hold the load without live air pressure; for true load-holding, consider an AirTAC SAIL or BSAI cylinder. This model uses a PT tapered port and supports the SAIJ mounting subset: Basic, FA, LB, TC, FTC, TCM1, and TCM2.

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/NPT/G)
  • ✓ Magnet (-S) for sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
  • check Installation by qualified personnel per AirTAC docs.

Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-20 FAQ

The rear adjuster acts as a mechanical stop that allows you to shorten the effective travel from the 1000 mm nominal stroke down to 980 mm. It is a travel stop only and does not lock or hold the load without continuous air pressure.
