AirTAC SAI Series · ISO 15552 Cylinder

Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-30

The AirTAC Adjustable Cylinder SAIJ32 SAIJ32X1000-30 is a genuine double-acting ISO 15552 profile-barrel air cylinder with a Ø32mm bore and 1000mm stroke, G1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ32 mm
  • Stroke1000 mm
  • Port sizeG1/8
  • Acting typeDouble acting
  • Rod threadM10×1.25
  • CushionAdjustable, 27 mm
$143.27 $150.77Save 4% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SAIJ32 stroke, mounting and version on one page All SAIJ32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-30

The AirTAC SAIJ32X1000-30 is a double-acting ISO 15552 profile cylinder featuring a rear stroke adjuster. Because the 1000mm stroke exceeds the standard maximum for this 32mm bore, it is manufactured as a non-standard, made-to-order unit. The rear adjustment screw allows you to fine-tune the effective travel down by up to 30mm, creating a 970-1000mm usable window for precise end-position tuning without adding external stops.

This adjustable-stroke design is ideal for product changeovers where minor position differences exist. The extruded aluminum barrel includes sensor grooves on both sides, ready for CMSE reed or DMSE electronic solid-state switches if a magnet is added later. It uses a reduced mounting set of Basic, FA, LB, TC, FTC, TCM1, and TCM2, omitting FB, CA, CB, and CR options. The PT tapered port threads match the standard G1/8 air connection for this bore size.

Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-30 Technical Specifications

ModelAirtac Adjustable Cylinder SAIJ32 SAIJ32X1000-30
SeriesSAI ISO 15552 profile cylinder
Bore sizeØ32 mm
Stroke1000 mm
Acting typeDouble acting
Port sizeG1/8
Rod threadM10×1.25
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C
Speed range30 – 800 mm/s
CushionAdjustable, 27 mm
Max strokeUp to 1000 mm

Specifications follow the official AirTAC SAI series datasheet and ISO 15552 dimensions. Confirm against the product label before installation. Port options: G (BSPP) / NPT.

Theoretical Output Force (Ø32mm)

PressurePush forcePull force
0.5 MPa346 N346 N
0.7 MPa484 N—
Max (@1.0 MPa)70 kgf

Double-rod model: the rod passes through the rear cover, so both piston faces lose rod area and push is shown at the annular-area value. Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-30

SAIISO 15552 profile-barrel cylinder series.
32Bore size in mm.
×1000Stroke length in mm.
-SOptional built-in magnet for sensor position sensing.

Related SAI-family variants: SAID (double rod), SAIJ (adjustable stroke), SAIL (with lock), SAIF (with valve), BSAI (enclasp / clamp-lock), and SAI-S with built-in magnet. Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B); seals: TPU (blank) / Viton H / NBR N.

Where the Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-30 Is Used

settings_input_component

Machine Changeover

Dial in the 970-1000mm travel window during product size changes without swapping the cylinder or repositioning external hard stops.

precision_manufacturing

End-Position Tuning

Fine-tune the retract end position during commissioning to achieve exact placement without adding mechanical spacers.

Is the Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-30 the Right Cylinder?

Select the SAIJ32X1000-30 when you need exact end-position dialing during commissioning on a long-stroke machine. If your application requires less travel, stepping down to a 32mm bore with a shorter stroke is advised. Remember that the rear adjuster acts only as a travel stop and does not hold the load without live air pressure; for true load-holding, consider an SAIL air-released lock, a BSAI clamp-lock, or an external rod lock.

Because this is a 1000mm stroke, the 12mm rod and M10x1.25 thread will experience significant leverage under side loading; an external guide rail is strongly recommended to prevent rod bearing wear. This cylinder is dimensionally interchangeable per ISO 15552, featuring a PT port, carbon steel rod, and no magnet. If fixed travel is acceptable, a standard SAI cylinder offers the same ISO 15552 footprint without the adjustment hardware.

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/NPT/G)
  • ✓ Magnet (-S) for sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
  • check Installation by qualified personnel per AirTAC docs.

Airtac Adjustable Cylinder SAIJ32 SAIJ32X1000-30 FAQ

At 0.7 MPa, the push force increases to 563N.

The rear adjuster screw lets you shorten the 1000mm nominal stroke by up to 30mm, giving a usable travel window of 970-1000mm. This allows fine-tuning of the end position at commissioning without swapping the cylinder.
