Airtac PBD Pen-shaped Double Rod Cylinder PBD6X35S
The AirTAC PBD Pen-shaped Double Rod Cylinder PBD6X35S is a double-acting pen-size mini cylinder with a piston rod protruding from both covers. The twin rods share one piston, giving equal push and pull force, resisting rotation and providing a spare mounting or sensing end on a Ø6mm bore, 35mm stroke.
- BoreØ6 mm
- Stroke35 mm
- Port sizeM5×0.8
- Acting typeDouble acting, double rod
- Rod threadM5×0.8
- ForceEqual both ways
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PBD Pen-shaped Double Rod Cylinder PBD6X35S
The AirTAC PBD6X35S is a double-acting, double-rod pen-size mini cylinder with a 6 mm bore and 35 mm stroke. A piston rod protrudes from both covers on a single piston, meaning both chambers act on the same rod-side annular area. This geometry yields perfectly equal push and pull forces, delivering 10.6 N in both directions at 0.5 MPa.
The twin Ø3 mm stainless steel rods resist twist better than a single rod and provide a spare end for mounting a sensor flag or external stop. The slim SUS304 body saves space in tight jigs. A fixed TPU bumper at each end decelerates the last few millimeters of travel. Because this unit includes the -S option, a built-in piston magnet enables position sensing with reed or electronic switches.
Airtac PBD Pen-shaped Double Rod Cylinder PBD6X35S Technical Specifications
| Model | Airtac PBD Pen-shaped Double Rod Cylinder PBD6X35S |
|---|---|
| Series | PBD JIS pen-size double-rod cylinder |
| Bore size | Ø6 mm |
| Rod diameter | Ø3 mm (both ends) |
| Stroke | 35 mm |
| Acting type | Double acting, double rod |
| Port size | M5×0.8 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 0.7 MPa |
| Proof pressure | 1.2 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Cushion | Elastic bumper (both ends) |
| Max standard stroke | Up to 50 mm |
Both chambers act on the rod-side annular area, so push and pull forces are equal. Piston rod and barrel are stainless steel. Confirm against the product label before installation.
Theoretical Output Force (Ø6mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 10.6 N | 10.6 N |
| 0.7 MPa (max) | 14.8 N | 14.8 N |
Because a rod occupies both chambers, the effective area is identical on each side — push and pull forces match. Values are from the AirTAC thrust table (rod-side / pull column). Size with a friction margin.
Model Code: Airtac PBD Pen-shaped Double Rod Cylinder PBD6X35S
| PBD | JIS pen-size double-rod mini-cylinder series. |
|---|---|
| 6 | Bore size in mm. |
| ×35 | Stroke length in mm. |
| S | Built-in magnet for magnetic-switch position sensing (omit = no magnet). |
Fixed body — no separate back-cover code. Mounting accessories: LB, FA. Related PB-family variants: PB (single rod), PBJ (adjustable stroke), PBR (front-mount).
Where the Airtac PBD Pen-shaped Double Rod Cylinder PBD6X35S Is Used
Dual-Side Transfer
Pushes a part forward on the extend stroke and retracts a second part simultaneously, utilizing the equal push and pull force for balanced dual-side conveyor loading.
Sensor-Flagged Index
Uses the spare rod end to carry a flag for a reed or electronic switch, confirming position without adding external hardware to the primary tooling side.
Symmetric Clamp
Clamps a delicate workpiece from both sides at once. The twin rods resist rotational twist, keeping the jaws aligned during repetitive light-duty tasks.
Is the Airtac PBD Pen-shaped Double Rod Cylinder PBD6X35S the Right Cylinder?
When sizing this 6 mm bore model, consider the neighboring 10 mm bore which provides 33.0 N at 0.5 MPa if you need more force. Downward, there is no smaller PB bore, so this is the most compact option available. Both directions yield 10.6 N at 0.5 MPa, making it ideal for symmetric duty. Both ends require rod clearance across the full 35 mm stroke. Confirm your ordering essentials: 6 mm bore, 35 mm stroke, S magnet, and your preferred mount.
Quick checklist
- ✓ Need equal force in both directions
- ✓ Second rod end for a sensor / stop / flag
- ✓ Better anti-rotation than a single rod
- ✓ Magnet (S) for sensors?
- ✓ Clearance for the rod on both ends
- ✓ Keep the load coaxial — avoid side load
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 0.7 MPa operating pressure.
- check Leave clearance for the rod at both ends.
- check Keep the load coaxial; avoid side load on the thin rods.
- check Do not dismantle the front or back cover.
- check Fit dust caps to ports during long-term storage.
Airtac PBD Pen-shaped Double Rod Cylinder PBD6X35S FAQ
The push and pull forces are equal because both chambers act on the same rod-side area. It generates 10.6 N at 0.5 MPa and 14.8 N at the maximum operating pressure of 0.7 MPa.
Yes. The spare rod end can carry a sensor flag or external stop. This specific model includes the S option for a built-in magnet, allowing you to mount reed or electronic switches directly to the body.
