Airtac PBD Pen-shaped Double Rod Cylinder PBD6X50
The AirTAC PBD Pen-shaped Double Rod Cylinder PBD6X50 is a double-acting pen-size mini cylinder with a piston rod protruding from both covers. The twin rods share one piston, giving equal push and pull force, resisting rotation and providing a spare mounting or sensing end on a Ø6mm bore, 50mm stroke.
- BoreØ6 mm
- Stroke50 mm
- Port sizeM5×0.8
- Acting typeDouble acting, double rod
- Rod threadM5×0.8
- ForceEqual both ways
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PBD Pen-shaped Double Rod Cylinder PBD6X50
The AirTAC PBD6X50 is a double-acting, double-rod pen-size mini cylinder with a 6 mm bore and 50 mm stroke. Because a rod exits both covers on one shared piston, the chambers act on the same annular area, yielding 10.6 N of equal push and pull force at 0.5 MPa. The SUS304 stainless barrel and slim body fit tight jigs and light end-of-arm tooling.
Twin rods resist twist better than a single rod, while the spare end can carry a sensor flag or second tool. Air connects via an M5x0.8 port, and a fixed TPU bumper cushions each end.
Airtac PBD Pen-shaped Double Rod Cylinder PBD6X50 Technical Specifications
| Model | Airtac PBD Pen-shaped Double Rod Cylinder PBD6X50 |
|---|---|
| Series | PBD JIS pen-size double-rod cylinder |
| Bore size | Ø6 mm |
| Rod diameter | Ø3 mm (both ends) |
| Stroke | 50 mm |
| Acting type | Double acting, double rod |
| Port size | M5×0.8 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 0.7 MPa |
| Proof pressure | 1.2 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Cushion | Elastic bumper (both ends) |
| Max standard stroke | Up to 50 mm |
Both chambers act on the rod-side annular area, so push and pull forces are equal. Piston rod and barrel are stainless steel. Confirm against the product label before installation.
Theoretical Output Force (Ø6mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 10.6 N | 10.6 N |
| 0.7 MPa (max) | 14.8 N | 14.8 N |
Because a rod occupies both chambers, the effective area is identical on each side — push and pull forces match. Values are from the AirTAC thrust table (rod-side / pull column). Size with a friction margin.
Model Code: Airtac PBD Pen-shaped Double Rod Cylinder PBD6X50
| PBD | JIS pen-size double-rod mini-cylinder series. |
|---|---|
| 6 | Bore size in mm. |
| ×50 | Stroke length in mm. |
| S | Built-in magnet for magnetic-switch position sensing (omit = no magnet). |
Fixed body — no separate back-cover code. Mounting accessories: LB, FA. Related PB-family variants: PB (single rod), PBJ (adjustable stroke), PBR (front-mount).
Where the Airtac PBD Pen-shaped Double Rod Cylinder PBD6X50 Is Used
Dual-Side Transfer
Moves small electronic parts equally well in both directions, using the matching push and pull forces to shuttle items between stations.
Symmetric Clamp
Clamps a delicate workpiece from opposite sides. The twin rods resist rotation, keeping the jaw aligned under off-center contact.
Sensor-Flagged Index
Uses the spare rod end to trigger an external flag. The primary end drives the load, leaving the secondary end free for tracking.
Is the Airtac PBD Pen-shaped Double Rod Cylinder PBD6X50 the Right Cylinder?
This 6 mm bore reaches its 50 mm maximum standard stroke, so for longer travel step up to a 10 mm bore (33.0 N at 0.5 MPa). If your pull-dominant or symmetric duty needs less than 10.6 N, a smaller option is not available in this series. Both ends require rod clearance across the full travel. Confirm your ordering essentials: bore, stroke, no magnet, and mount.
Quick checklist
- ✓ Need equal force in both directions
- ✓ Second rod end for a sensor / stop / flag
- ✓ Better anti-rotation than a single rod
- ✓ Magnet (S) for sensors?
- ✓ Clearance for the rod on both ends
- ✓ Keep the load coaxial — avoid side load
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 0.7 MPa operating pressure.
- check Leave clearance for the rod at both ends.
- check Keep the load coaxial; avoid side load on the thin rods.
- check Do not dismantle the front or back cover.
- check Fit dust caps to ports during long-term storage.
Airtac PBD Pen-shaped Double Rod Cylinder PBD6X50 FAQ
It provides equal push and pull forces of 10.6 N at 0.5 MPa and 14.8 N at 0.7 MPa, which is the maximum operating pressure.
Yes. The spare rod end can carry a flag or stop without extra hardware. Note this specific model lacks a built-in magnet, so external tracking is required.
