Airtac PBD Pen-shaped Double Rod Cylinder PBD6X40
The AirTAC PBD Pen-shaped Double Rod Cylinder PBD6X40 is a double-acting pen-size mini cylinder with a piston rod protruding from both covers. The twin rods share one piston, giving equal push and pull force, resisting rotation and providing a spare mounting or sensing end on a Ø6mm bore, 40mm stroke.
- BoreØ6 mm
- Stroke40 mm
- Port sizeM5×0.8
- Acting typeDouble acting, double rod
- Rod threadM5×0.8
- ForceEqual both ways
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PBD Pen-shaped Double Rod Cylinder PBD6X40
The AirTAC PBD6X40 is a double-acting, double-rod pen-size mini cylinder. A piston rod protrudes from both covers, meaning both chambers act on the same rod-side annular area. This geometry delivers exactly 10.6 N of push and pull at 0.5 MPa. The SUS304 stainless barrel and rods provide a slim footprint for compact jigs.
Because the twin rods share one piston, they resist twist better than a single rod. The second end can carry a sensor flag or external stop without extra hardware. The fixed TPU bumper at each end decelerates the last few millimeters of travel.
Airtac PBD Pen-shaped Double Rod Cylinder PBD6X40 Technical Specifications
| Model | Airtac PBD Pen-shaped Double Rod Cylinder PBD6X40 |
|---|---|
| Series | PBD JIS pen-size double-rod cylinder |
| Bore size | Ø6 mm |
| Rod diameter | Ø3 mm (both ends) |
| Stroke | 40 mm |
| Acting type | Double acting, double rod |
| Port size | M5×0.8 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 0.7 MPa |
| Proof pressure | 1.2 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Cushion | Elastic bumper (both ends) |
| Max standard stroke | Up to 50 mm |
Both chambers act on the rod-side annular area, so push and pull forces are equal. Piston rod and barrel are stainless steel. Confirm against the product label before installation.
Theoretical Output Force (Ø6mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 10.6 N | 10.6 N |
| 0.7 MPa (max) | 14.8 N | 14.8 N |
Because a rod occupies both chambers, the effective area is identical on each side — push and pull forces match. Values are from the AirTAC thrust table (rod-side / pull column). Size with a friction margin.
Model Code: Airtac PBD Pen-shaped Double Rod Cylinder PBD6X40
| PBD | JIS pen-size double-rod mini-cylinder series. |
|---|---|
| 6 | Bore size in mm. |
| ×40 | Stroke length in mm. |
| S | Built-in magnet for magnetic-switch position sensing (omit = no magnet). |
Fixed body — no separate back-cover code. Mounting accessories: LB, FA. Related PB-family variants: PB (single rod), PBJ (adjustable stroke), PBR (front-mount).
Where the Airtac PBD Pen-shaped Double Rod Cylinder PBD6X40 Is Used
Dual-Side Transfer
Pushes a part from one belt to another using one rod, while the opposite rod simultaneously retracts a second part for continuous indexing.
Symmetric Clamp
Clamps a thin workpiece from both sides simultaneously, utilizing the equal push and pull forces to keep delicate components centered.
Sensor-Flagged Index
Uses the primary rod for light thrusting while the spare rear rod end mounts a physical flag to trigger an external limit switch.
Is the Airtac PBD Pen-shaped Double Rod Cylinder PBD6X40 the Right Cylinder?
This 6 mm bore generates 10.6 N in both directions at 0.5 MPa. If your application requires less force, a smaller pen cylinder is appropriate, but for more thrust, stepping up to a 10 mm bore yields 33.0 N. Remember that both ends require rod clearance across the full 40 mm stroke. The air port is M5x0.8 and the rod-end thread is M5x0.8. Confirm your ordering essentials: bore, stroke, magnet (this model has none), and mounting.
Quick checklist
- ✓ Need equal force in both directions
- ✓ Second rod end for a sensor / stop / flag
- ✓ Better anti-rotation than a single rod
- ✓ Magnet (S) for sensors?
- ✓ Clearance for the rod on both ends
- ✓ Keep the load coaxial — avoid side load
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 0.7 MPa operating pressure.
- check Leave clearance for the rod at both ends.
- check Keep the load coaxial; avoid side load on the thin rods.
- check Do not dismantle the front or back cover.
- check Fit dust caps to ports during long-term storage.
Airtac PBD Pen-shaped Double Rod Cylinder PBD6X40 FAQ
The PBD6X40 provides an equal push and pull force of 10.6 N at 0.5 MPa and 14.8 N at 0.7 MPa. The maximum operating pressure is 0.7 MPa.
No, a plain double-rod cylinder drifts when air loss occurs. The fixed TPU bumper only decelerates near the stroke end and does not act as a lock. You need an external stop or rod lock to hold a load safely.
