Airtac PBD Pen-shaped Double Rod Cylinder PBD6X45S
The AirTAC PBD Pen-shaped Double Rod Cylinder PBD6X45S is a double-acting pen-size mini cylinder with a piston rod protruding from both covers. The twin rods share one piston, giving equal push and pull force, resisting rotation and providing a spare mounting or sensing end on a Ø6mm bore, 45mm stroke.
- BoreØ6 mm
- Stroke45 mm
- Port sizeM5×0.8
- Acting typeDouble acting, double rod
- Rod threadM5×0.8
- ForceEqual both ways
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac PBD Pen-shaped Double Rod Cylinder PBD6X45S
The AirTAC PBD6X45S is a double-acting, double-rod pen-size mini cylinder. A piston rod protrudes from both covers on a single piston, meaning both chambers act on the same rod-side annular area. This geometry yields equal push and pull forces, giving you about 10.6 N of thrust in both directions at 0.5 MPa.
The twin rods resist twist better than a single rod, while the second end can carry a sensor flag or external stop without extra hardware. The SUS304 stainless build includes a fixed TPU bumper at each end. Since this variant includes the S option, a built-in piston magnet enables position sensing with reed or electronic switches.
Airtac PBD Pen-shaped Double Rod Cylinder PBD6X45S Technical Specifications
| Model | Airtac PBD Pen-shaped Double Rod Cylinder PBD6X45S |
|---|---|
| Series | PBD JIS pen-size double-rod cylinder |
| Bore size | Ø6 mm |
| Rod diameter | Ø3 mm (both ends) |
| Stroke | 45 mm |
| Acting type | Double acting, double rod |
| Port size | M5×0.8 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 0.7 MPa |
| Proof pressure | 1.2 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 50 – 800 mm/s |
| Cushion | Elastic bumper (both ends) |
| Max standard stroke | Up to 50 mm |
Both chambers act on the rod-side annular area, so push and pull forces are equal. Piston rod and barrel are stainless steel. Confirm against the product label before installation.
Theoretical Output Force (Ø6mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 10.6 N | 10.6 N |
| 0.7 MPa (max) | 14.8 N | 14.8 N |
Because a rod occupies both chambers, the effective area is identical on each side — push and pull forces match. Values are from the AirTAC thrust table (rod-side / pull column). Size with a friction margin.
Model Code: Airtac PBD Pen-shaped Double Rod Cylinder PBD6X45S
| PBD | JIS pen-size double-rod mini-cylinder series. |
|---|---|
| 6 | Bore size in mm. |
| ×45 | Stroke length in mm. |
| S | Built-in magnet for magnetic-switch position sensing (omit = no magnet). |
Fixed body — no separate back-cover code. Mounting accessories: LB, FA. Related PB-family variants: PB (single rod), PBJ (adjustable stroke), PBR (front-mount).
Where the Airtac PBD Pen-shaped Double Rod Cylinder PBD6X45S Is Used
Dual-Side Transfer
Pushes a part forward on the extension stroke and retracts a second fixture simultaneously, leveraging the equal force on both ends for balanced inline automation.
Sensor-Flagged Index
Uses the primary rod to drive a light pick-and-place motion while the spare rear rod directly triggers an external reed or electronic switch for precise position confirmation.
Symmetric Clamp
Secures a delicate workpiece from two opposite sides at once, utilizing the anti-rotation properties of the twin rods to keep the clamping faces perfectly aligned.
Is the Airtac PBD Pen-shaped Double Rod Cylinder PBD6X45S the Right Cylinder?
This 6 mm bore develops 10.6 N of force both ways at 0.5 MPa. If you need less power, moving down is not an option as this is the smallest size, but sizing up to a 10 mm bore raises the output to 33.0 N.
Keep layout in mind: both ends require rod clearance across the full 45 mm stroke. The air port is M5x0.8, and the rod-end thread is M5x0.8. Confirm your ordering essentials: 6 mm bore, 45 mm stroke, S magnet, and your preferred mounting option.
Quick checklist
- ✓ Need equal force in both directions
- ✓ Second rod end for a sensor / stop / flag
- ✓ Better anti-rotation than a single rod
- ✓ Magnet (S) for sensors?
- ✓ Clearance for the rod on both ends
- ✓ Keep the load coaxial — avoid side load
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 0.7 MPa operating pressure.
- check Leave clearance for the rod at both ends.
- check Keep the load coaxial; avoid side load on the thin rods.
- check Do not dismantle the front or back cover.
- check Fit dust caps to ports during long-term storage.
Airtac PBD Pen-shaped Double Rod Cylinder PBD6X45S FAQ
The push and pull forces are equal because a rod occupies both chambers. It generates 10.6 N at 0.5 MPa and 14.8 N at the maximum operating pressure of 0.7 MPa.
The twin rods share one piston to resist twist better than a single rod. The spare protruding end can carry a sensor flag, external stop, or second tool without requiring additional mounting hardware.
