Airtac SC32 Standard Cylinder SC32X100FB
The AirTAC Airtac SC32 Standard Cylinder SC32X100FB is a genuine double-acting standard air cylinder with a Ø32mm bore and 100mm stroke, PT1/8 air ports and adjustable end cushioning. It is used for push, pull, lift and clamp motion in industrial automation.
- BoreØ32 mm
- Stroke100 mm
- Port sizePT1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 21 mm
About the Airtac SC32 Standard Cylinder SC32X100FB
The SC32X100FB is a compact double-acting tie-rod cylinder delivering 402 N of push force at 0.5 MPa (724 N at the maximum operating pressure of 0.9 MPa). Its 12 mm diameter piston rod and 21 mm adjustable air cushion make it suitable for light automation tasks requiring precise end-of-stroke deceleration.
This model is factory-configured with an FB rear rectangular flange (mounting accessory F-SC32FB) for secure end-face mounting. The 100 mm stroke falls well within the standard range for the 32 mm bore, and the PT1/8 ports provide a reliable pneumatic connection.
Airtac SC32 Standard Cylinder SC32X100FB Technical Specifications
| Model | Airtac SC32 Standard Cylinder SC32X100FB |
|---|---|
| Series | SC standard tie-rod cylinder |
| Bore size | Ø32 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | PT1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 21 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SC series datasheet. Operating pressure 0.15–1.0 MPa, proof pressure 1.5 MPa, temperature −20 to +70 °C. Confirm against the product label before installation. Thread options: PT (standard) / G.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (approx.) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SC32 Standard Cylinder SC32X100FB
| SC | Standard tie-rod cylinder series. |
|---|---|
| 32 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related variants: SCD (double rod), SCJ (adjustable stroke), SCT (multi-position). Seals: TPU standard / H = Viton / N = NBR. Thread: blank = PT, G = G thread.
Where the Airtac SC32 Standard Cylinder SC32X100FB Is Used
Small Part Diverting
The 100 mm stroke and 402 N force at 0.5 MPa are ideal for pushing lightweight components off a conveyor belt in packaging lines.
Clamping Fixtures
Use the rear flange mount for a rigid setup on a jig, applying consistent clamping force to hold parts during light machining or assembly.
Actuating Safety Gates
The double-acting control and adjustable cushion smoothly open and close small machine guards without slamming.
Is the Airtac SC32 Standard Cylinder SC32X100FB the Right Cylinder?
Choose the SC32 when your application needs up to 402 N of force at standard plant pressure. If you require more power, stepping up to the SC40 provides 628 N at the same 0.5 MPa. For this 100 mm stroke, the rod is well-supported, but always avoid direct side loads.
To guarantee a drop-in replacement, match five key points: 32 mm bore, 100 mm stroke, PT1/8 port thread, FB rear flange mounting, and ensure the magnet option (-S) matches your sensor setup.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SC32 Standard Cylinder SC32X100FB FAQ
At 0.7 MPa operating pressure, the theoretical push force is 563 N. The pull force on the retract stroke is lower due to the rod area, rated at 345 N at 0.5 MPa.
No. The AirTAC SC series is a tie-rod cylinder with a shorter body length than ISO 15552 profile cylinders. It is not dimensionally interchangeable. Only replace it with another AirTAC SC32 tie-rod cylinder matching the stroke, port, and mounting.
