Airtac SC32 Standard Cylinder SC32X200
The AirTAC Airtac SC32 Standard Cylinder SC32X200 is a genuine double-acting standard air cylinder with a Ø32mm bore and 200mm stroke, PT1/8 air ports and adjustable end cushioning. It is used for push, pull, lift and clamp motion in industrial automation.
- BoreØ32 mm
- Stroke200 mm
- Port sizePT1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 21 mm
About the Airtac SC32 Standard Cylinder SC32X200
The SC32X200 is a compact double-acting tie-rod cylinder delivering 402 N of push force at 0.5 MPa, rising to 724 N at the maximum operating pressure of 0.9 MPa. Its 12 mm diameter piston rod and 21 mm adjustable air cushion provide reliable deceleration for light automation tasks.
With a body length A of 140 mm and a 200 mm stroke, this genuine AirTAC unit is well-suited to space-constrained applications. The PT1/8 port and M10x1.25 rod thread offer standard connectivity, while the TPU seals ensure smooth operation in ambient temperatures from -20 to +70 °C.
Airtac SC32 Standard Cylinder SC32X200 Technical Specifications
| Model | Airtac SC32 Standard Cylinder SC32X200 |
|---|---|
| Series | SC standard tie-rod cylinder |
| Bore size | Ø32 mm |
| Stroke | 200 mm |
| Acting type | Double acting |
| Port size | PT1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 21 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SC series datasheet. Operating pressure 0.15–1.0 MPa, proof pressure 1.5 MPa, temperature −20 to +70 °C. Confirm against the product label before installation. Thread options: PT (standard) / G.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (approx.) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SC32 Standard Cylinder SC32X200
| SC | Standard tie-rod cylinder series. |
|---|---|
| 32 | Bore size in mm. |
| ×200 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related variants: SCD (double rod), SCJ (adjustable stroke), SCT (multi-position). Seals: TPU standard / H = Viton / N = NBR. Thread: blank = PT, G = G thread.
Where the Airtac SC32 Standard Cylinder SC32X200 Is Used
Small-Part Sorting
The 200 mm stroke and 402 N push force at 0.5 MPa reliably actuate gates or diverters on compact conveyor lines, separating lightweight components in packaging or electronics assembly.
Lab Automation
Ideal for test-tube handling or microplate positioning, the SC32X200 provides smooth, controlled motion with an adjustable cushion to protect delicate samples from impact shock.
Label Applicators
Delivers a clean, repeatable 200 mm extension to press labels onto products. The tie-rod design allows easy maintenance in high-cycle labelling stations.
Is the Airtac SC32 Standard Cylinder SC32X200 the Right Cylinder?
Choose the SC32X200 for light-duty pushing, clamping, or sorting where force requirements stay below 724 N. If your load demands more thrust, step up to the SC40 bore, which provides 628 N at 0.5 MPa. For strokes of 200 mm on a 12 mm rod, ensure the load is guided and free of side forces; an external guide rail prevents rod bending and premature seal wear.
For a direct replacement, match five key points: 32 mm bore, 200 mm stroke, PT port thread, basic (no bracket) mounting, and no magnet. This ensures dimensional and performance interchangeability with an existing AirTAC SC32X200 tie-rod cylinder.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SC32 Standard Cylinder SC32X200 FAQ
At 0.5 MPa, the push force is 402 N and the pull force is 345 N. At the maximum operating pressure of 0.9 MPa, the push force reaches 724 N. The theoretical maximum force at 1.0 MPa is 82 kgf.
No. The SC series is a tie-rod cylinder and is physically shorter than an ISO 15552 cylinder of the same bore and stroke, so it is not dimensionally interchangeable. Only replace another AirTAC SC32X200 or a tie-rod cylinder with identical bore, stroke, port thread, and mounting.
