Airtac SC32 Standard Cylinder SC32X100SH
The AirTAC Airtac SC32 Standard Cylinder SC32X100SH is a genuine double-acting standard air cylinder with a Ø32mm bore and 100mm stroke, PT1/8 air ports and adjustable end cushioning. It is used for push, pull, lift and clamp motion in industrial automation.
- BoreØ32 mm
- Stroke100 mm
- Port sizePT1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 21 mm
About the Airtac SC32 Standard Cylinder SC32X100SH
The SC32X100SH is a compact double-acting pneumatic cylinder delivering 402 N of push force at 0.5 MPa, ideal for light-duty clamping and sorting tasks. Its 12 mm diameter piston rod and 21 mm adjustable air cushion provide smooth deceleration across the 100 mm stroke.
This model features a built-in magnet (suffix S) for direct mounting of CMSG/DMSG/EMSG sensors, enabling precise end-of-stroke detection. The H suffix specifies Viton (FKM) seals, extending the operating temperature range to 0-150°C for reliable performance in hot environments.
Airtac SC32 Standard Cylinder SC32X100SH Technical Specifications
| Model | Airtac SC32 Standard Cylinder SC32X100SH |
|---|---|
| Series | SC standard tie-rod cylinder |
| Bore size | Ø32 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | PT1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 21 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SC series datasheet. Operating pressure 0.15–1.0 MPa, proof pressure 1.5 MPa, temperature −20 to +70 °C. Confirm against the product label before installation. Thread options: PT (standard) / G.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (approx.) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SC32 Standard Cylinder SC32X100SH
| SC | Standard tie-rod cylinder series. |
|---|---|
| 32 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related variants: SCD (double rod), SCJ (adjustable stroke), SCT (multi-position). Seals: TPU standard / H = Viton / N = NBR. Thread: blank = PT, G = G thread.
Where the Airtac SC32 Standard Cylinder SC32X100SH Is Used
Hot-Zone Actuation
Viton seals withstand 0-150°C, making this cylinder suitable for autoclave door mechanisms, drying ovens, or foundry pattern-draw equipment where standard seals would fail.
Sensor-Controlled Sorting
The built-in magnet allows CMSG/DMSG sensors to confirm extend/retract position, ideal for small-part sorting gates or diverters on packaging lines requiring cycle verification.
Compact Clamping Fixtures
With 402 N of force at 0.5 MPa, this 32 mm bore cylinder fits tight weld fixtures and assembly jigs, providing consistent clamping pressure in a space-saving tie-rod design.
Is the Airtac SC32 Standard Cylinder SC32X100SH the Right Cylinder?
For applications needing more force, the SC40 series offers 628 N push at 0.5 MPa. When replacing an existing cylinder, match all five key points: 32 mm bore, 100 mm stroke, PT port thread, the built-in magnet for sensor compatibility, and the high-temperature Viton seal material. The SC is a tie-rod cylinder and is not dimensionally interchangeable with ISO 15552 profiles.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SC32 Standard Cylinder SC32X100SH FAQ
At the standard operating pressure of 0.5 MPa, it generates 402 N pushing and 345 N pulling. At the maximum operating pressure of 0.9 MPa, the pushing force increases to 724 N.
Yes. The 'S' in the model code indicates a built-in magnet, allowing AirTAC CMSG (reed) or DMSG/EMSG (solid-state) sensors to be mounted directly on the tie-rod barrel for position sensing.
