Airtac SC32 Standard Cylinder SC32X150
The AirTAC Airtac SC32 Standard Cylinder SC32X150 is a genuine double-acting standard air cylinder with a Ø32mm bore and 150mm stroke, PT1/8 air ports and adjustable end cushioning. It is used for push, pull, lift and clamp motion in industrial automation.
- BoreØ32 mm
- Stroke150 mm
- Port sizePT1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 21 mm
About the Airtac SC32 Standard Cylinder SC32X150
The SC32X150 is a compact double-acting tie-rod cylinder delivering 402 N of push force at 0.5 MPa (563 N at 0.7 MPa), making it a capable actuator for light automation tasks. Its 12 mm diameter piston rod and 21 mm adjustable air cushion provide smooth deceleration at end-of-stroke, while the 140 mm body length keeps the overall footprint short.
With a 150 mm stroke well within the 1000 mm maximum standard range for this 32 mm bore, this cylinder is a stock-configuration workhorse. The PT1/8 ports and M10x1.25 rod thread ensure straightforward pneumatic connections and tooling attachment.
Airtac SC32 Standard Cylinder SC32X150 Technical Specifications
| Model | Airtac SC32 Standard Cylinder SC32X150 |
|---|---|
| Series | SC standard tie-rod cylinder |
| Bore size | Ø32 mm |
| Stroke | 150 mm |
| Acting type | Double acting |
| Port size | PT1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 21 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SC series datasheet. Operating pressure 0.15–1.0 MPa, proof pressure 1.5 MPa, temperature −20 to +70 °C. Confirm against the product label before installation. Thread options: PT (standard) / G.
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (approx.) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SC32 Standard Cylinder SC32X150
| SC | Standard tie-rod cylinder series. |
|---|---|
| 32 | Bore size in mm. |
| ×150 | Stroke length in mm. |
| -S | Optional built-in magnet for sensor position sensing. |
Related variants: SCD (double rod), SCJ (adjustable stroke), SCT (multi-position). Seals: TPU standard / H = Viton / N = NBR. Thread: blank = PT, G = G thread.
Where the Airtac SC32 Standard Cylinder SC32X150 Is Used
Small Part Clamping
The 402 N push force at 0.5 MPa is ideal for fixturing and clamping small components during light machining or assembly operations.
Diverter Gates
Use this 32 mm bore cylinder to actuate compact diverter gates on packaging lines, where a 150 mm stroke provides sufficient travel for product sorting.
Test Stand Actuation
Deploy the SC32X150 in benchtop test fixtures requiring a reliable, repeatable 150 mm linear motion with adjustable cushioning for smooth operation.
Is the Airtac SC32 Standard Cylinder SC32X150 the Right Cylinder?
Choose the SC32X150 when your application needs around 400 N of force from a compact cylinder. If you require more thrust, stepping up to the SC40 series provides 628 N at the same 0.5 MPa pressure. For strokes of 300 mm or longer on this 12 mm rod, be mindful of side loads—consider an external linear guide to prevent rod bending and premature seal wear. When replacing an existing unit, match the 32 mm bore, 150 mm stroke, PT1/8 port thread, and basic mounting configuration exactly.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/NPT/G)
- ✓ Magnet (-S) for sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (FA/FB/CA/CB/LB/TC).
- check Installation by qualified personnel per AirTAC docs.
Airtac SC32 Standard Cylinder SC32X150 FAQ
At the standard operating pressure of 0.5 MPa, the SC32X150 generates 402 N of force when extending (push) and 345 N when retracting (pull). At the maximum operating pressure of 0.9 MPa, the push force increases to 724 N.
No. The AirTAC SC series is a tie-rod cylinder with a shorter body length than an ISO 15552 profile cylinder, so it is not dimensionally interchangeable. It is a direct replacement only for another AirTAC SC32 tie-rod cylinder with the same bore, stroke, and port thread.
