Airtac SDA Ultra Thin Cylinder SDA80X10
The AirTAC SDA Ultra Thin Cylinder SDA80X10 is a genuine double-acting COMPACT (thin) air cylinder with a Ø80mm bore and 10mm stroke, PT3/8 air ports and a riveted short body that saves mounting depth. Sensor slots around the body accept magnetic switches for position sensing.
- BoreØ80 mm
- Stroke10 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM14×1.5 (F) / M22×1.5 (B)
- CushionFixed NBR bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SDA Ultra Thin Cylinder SDA80X10
The AirTAC SDA80X10 is a double-acting single-rod compact cylinder engineered for heavy thrust within a minimal axial envelope. It delivers 2513.3 N of push force and 2267.8 N of pull force at 0.5 MPa, operating via a PT3/8 port and a 25 mm piston rod. The riveted body assembly significantly reduces overall length compared to round-body units, making it highly effective for tight machine footprints.
This specific configuration uses a fixed NBR bumper at each end to decelerate the stroke, which is not an adjustable air cushion. For high-energy cycles, an external shock absorber is advised. This SKU lacks a piston magnet, so it cannot support position sensing without upgrading to the -S variant for reed or electronic switches.
Airtac SDA Ultra Thin Cylinder SDA80X10 Technical Specifications
| Model | Airtac SDA Ultra Thin Cylinder SDA80X10 |
|---|---|
| Series | SDA compact (thin) cylinder |
| Bore size | Ø80 mm |
| Stroke | 10 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod end thread | M14×1.5 female / M22×1.5 male (B) |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
| Max standard stroke | Up to 120 mm |
Specifications follow the official AirTAC SDA compact-cylinder datasheet. Confirm against the product label before installation. Port thread: PT (standard). Rod: female thread (blank) / male thread (B).
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2513 N | 2268 N |
| 0.7 MPa | 3519 N | — |
| Max (@1.0 MPa) | 513 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SDA Ultra Thin Cylinder SDA80X10
| SDA | Compact (thin) double-acting cylinder series. |
|---|---|
| 80 | Bore size in mm. |
| ×10 | Stroke length in mm. |
| S | Built-in magnet for magnetic-switch position sensing (omit = no magnet). |
| B | Male-thread piston rod (omit = female-thread rod). |
Thread: PT standard. Related SDA-family variants: SSA (single-acting push), STA (single-acting pull), SDAD (double rod), SDAJ (adjustable stroke), SDAT (duplex), SDAW (duplex-end).
Where the Airtac SDA Ultra Thin Cylinder SDA80X10 Is Used
Injection Mold Platen Ejection
Drives short-stroke ejection pins on an injection molding platen where the 2513.3 N output clears finished plastic parts without requiring deep axial mounting.
Press Brake Tooling Clamp
Secures heavy upper tooling on a CNC press brake, utilizing the 25 mm rod and 10 mm stroke to lock the profile in place rapidly during quick-change setups.
Stamping Press Feed Stop
Acts as a rugged stop block in a coil feeding line, absorbing high side loads to halt metal strip advancement before the stamping press cycles.
Is the Airtac SDA Ultra Thin Cylinder SDA80X10 the Right Cylinder?
When sizing this unit, stepping down to the SDA63 yields 1558.6 N of push at 0.5 MPa, while stepping up to the SDA100 provides 3927 N. Confirm your ordering essentials: 80 mm bore, 10 mm stroke, PT3/8 port, female M14x1.5 rod thread, and no magnet.
Because this is a double-acting cylinder, it will not hold a load if air pressure drops or the valve is centered—the piston drifts, and the fixed bumper only decelerates near the stroke end. To maintain position safely, integrate an external rod lock or a pilot-operated check valve into your circuit.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short-body depth vs. a round-body cylinder
- ✓ Port/thread type (PT)
- ✓ Magnet (S) for sensors?
- ✓ Female (blank) or male (B) rod thread
- ✓ Side load — avoid on a compact rod
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the short piston rod.
- check Very long strokes are unsuitable for the compact body.
- check Front/rear covers are riveted — do not dismantle.
- check Installation by qualified personnel per AirTAC docs.
Airtac SDA Ultra Thin Cylinder SDA80X10 FAQ
At 0.5 MPa, this 80 mm bore cylinder provides 2513.3 N of push force and 2267.8 N of pull force. At 0.7 MPa, push increases to 3518.6 N. The theoretical maximum push is 513 kgf at 1.0 MPa. Operating pressure ranges from 0.15-1.0 MPa, with a speed of 30-500 mm/s.
No, this specific SKU does not include a piston magnet, so it cannot trigger magnetic switches. You must select the SDA80X10S variant to enable sensing with reed or electronic switches. Also, note it uses a fixed NBR bumper rather than an adjustable air cushion.
