Airtac SDA Ultra Thin Cylinder SDA80X5
The AirTAC Airtac SDA Ultra Thin Cylinder SDA80X5 is a genuine double-acting COMPACT (thin) air cylinder with a Ø80mm bore and 5mm stroke, PT3/8 air ports and a riveted short body that saves mounting depth. Sensor slots around the body accept magnetic switches for position sensing.
- BoreØ80 mm
- Stroke5 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM14×1.5 (F) / M22×1.5 (B)
- CushionFixed NBR bumper (both ends)
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SDA Ultra Thin Cylinder SDA80X5
The AirTAC SDA80X5 is a double-acting single-rod compact cylinder engineered for very short linear motion. It delivers a substantial 2513.3 N push and 2267.8 N pull force at 0.5 MPa, making it ideal for high-force pressing and short-stroke clamping. The hard-anodized bore and two-way piston seal ensure reliable service within the 0.15-1.0 MPa operating pressure range.
This model features a 5 mm stroke on a short riveted body, drastically reducing axial mounting depth where a longer round-body unit would fail to fit. It uses a 25 mm piston rod with an M14x1.5 female thread and PT3/8 air ports. End-stopping relies on a fixed NBR bumper rather than an adjustable air cushion, so high-energy cycles may require an external shock absorber. This specific SKU lacks a piston magnet and therefore cannot host magnetic switches.
Airtac SDA Ultra Thin Cylinder SDA80X5 Technical Specifications
| Model | Airtac SDA Ultra Thin Cylinder SDA80X5 |
|---|---|
| Series | SDA compact (thin) cylinder |
| Bore size | Ø80 mm |
| Stroke | 5 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod end thread | M14×1.5 female / M22×1.5 male (B) |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C |
| Speed range | 30 – 500 mm/s |
| Cushion | Fixed NBR bumper (both ends) |
| Max standard stroke | Up to 120 mm |
Specifications follow the official AirTAC SDA compact-cylinder datasheet. Confirm against the product label before installation. Port thread: PT (standard). Rod: female thread (blank) / male thread (B).
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2513 N | 2268 N |
| 0.7 MPa | 3519 N | — |
| Max (@1.0 MPa) | 513 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SDA Ultra Thin Cylinder SDA80X5
| SDA | Compact (thin) double-acting cylinder series. |
|---|---|
| 80 | Bore size in mm. |
| ×5 | Stroke length in mm. |
| S | Built-in magnet for magnetic-switch position sensing (omit = no magnet). |
| B | Male-thread piston rod (omit = female-thread rod). |
Thread: PT standard. Related SDA-family variants: SSA (single-acting push), STA (single-acting pull), SDAD (double rod), SDAJ (adjustable stroke), SDAT (duplex), SDAW (duplex-end).
Where the Airtac SDA Ultra Thin Cylinder SDA80X5 Is Used
Short-Stroke Stamping
Executes brief 5 mm high-force stamping hits in progressive die tooling where 2513.3 N of extend force is required in a shallow frame.
Heavy Part Ejection
Ejects dense metal castings from machining fixtures using a compact 80 mm bore that minimizes interference with adjacent CNC spindles.
Riveting Head Actuation
Drives an orbital riveting head for 5 mm upset cycles, leveraging the rigid 25 mm rod to resist buckling under 2267.8 N retraction loads.
Is the Airtac SDA Ultra Thin Cylinder SDA80X5 the Right Cylinder?
When sizing this unit, compare its 2513.3 N push at 0.5 MPa against adjacent bores: stepping down to the SDA63 yields 1558.6 N, while stepping up to the SDA100 provides 3927 N. For this 80 mm bore, a safe working load is roughly 1508 N (about 60% of the 0.5 MPa figure), allowing a vertical lift of approximately 128.1 kg with a 2:1 safety margin. To finalize your order, confirm the 5 mm stroke, PT3/8 port, female rod thread, and the absence of a sensor magnet. Note that a plain compact cylinder drifts when air is lost or the valve is centered; the fixed bumper only decelerates the stroke end and does not act as a lock. If your application must hold a load without live pressure, install an external rod lock or a pilot-operated check valve.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Short-body depth vs. a round-body cylinder
- ✓ Port/thread type (PT)
- ✓ Magnet (S) for sensors?
- ✓ Female (blank) or male (B) rod thread
- ✓ Side load — avoid on a compact rod
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the short piston rod.
- check Very long strokes are unsuitable for the compact body.
- check Front/rear covers are riveted — do not dismantle.
- check Installation by qualified personnel per AirTAC docs.
Airtac SDA Ultra Thin Cylinder SDA80X5 FAQ
This double-acting 80 mm bore cylinder provides 2513.3 N push and 2267.8 N pull at 0.5 MPa, and 3518.6 N push at 0.7 MPa. The theoretical maximum push force is 513 kgf at 1.0 MPa, with a proof pressure of 1.5 MPa.
No, this specific SKU does not include a piston magnet. To use AirTAC reed or electronic switches in the body grooves, you must order the -S variant. Additionally, end stopping relies on a fixed NBR bumper, not an adjustable air cushion.
