Airtac SE80 Standard Cylinder SE80AX100
The AirTAC Airtac SE80 Standard Cylinder SE80AX100 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø80mm bore and 100mm stroke, PT3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ80 mm
- Stroke100 mm
- Port sizePT3/8
- Acting typeDouble acting
- Rod threadM20×1.5
- CushionAdjustable, 36 mm
About the Airtac SE80 Standard Cylinder SE80AX100
The AirTAC SE80AX100 is a double-acting single-rod profile cylinder built to ISO 15552 dimensions, delivering a robust 2513 N push at 0.5 MPa. It features a SUS420J2 stainless steel rod, making it highly suitable for corrosive environments or washdown duty where a standard carbon steel rod would fail. The extruded aluminum barrel design omits external tie rods, yielding a compact body that mounts flush against machine frames while resisting debris buildup.
This 80 mm bore unit operates at speeds from 30-800 mm/s and relies on field-adjustable air cushioning at both ends to decelerate the piston smoothly. Because this specific SKU lacks the -S magnet code, it is not equipped for CMSE or DMSE position sensing out of the box. The cushioning screws can be tuned to soften hard end stops at high velocities, ensuring quiet operation without fixed rubber bumpers.
Airtac SE80 Standard Cylinder SE80AX100 Technical Specifications
| Model | Airtac SE80 Standard Cylinder SE80AX100 |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø80 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | PT3/8 |
| Rod thread | M20×1.5 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 36 mm |
| Max stroke | Up to 1500 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø80mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 2513 N | 2268 N |
| 0.7 MPa | 3519 N | — |
| Max (@1.0 MPa) | 513 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE80 Standard Cylinder SE80AX100
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 80 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE80 Standard Cylinder SE80AX100 Is Used
Corrugated Box Forming
Drives the forming plates on a packaging line, using the 2513 N push force to fold heavy cardboard while the SUS420J2 rod withstands occasional washdowns.
Press Brake Alignment
Positions the backgauge on a sheet metal press brake, relying on the 100 mm stroke and adjustable end cushions to handle rapid, repetitive cycling.
Bottle Diverting Gate
Actuates a diverting arm on a beverage conveyor, where the stainless steel rod resists moisture and the 3518 N thrust at 0.7 MPa easily redirects full bottle lanes.
Is the Airtac SE80 Standard Cylinder SE80AX100 the Right Cylinder?
Selecting this 80 mm bore provides 2513 N of push force at 0.5 MPa. If your application requires less force, stepping down to the 63 mm bore yields 1559 N; if you need more power, stepping up to the 100 mm bore provides 3927 N. This model uses a PT3/8 port and an M20x1.5 rod thread, carrying significant side-load capacity, though any stroke exceeding 300 mm still necessitates an external guide to prevent rod-bearing bending.
As a standard ISO 15552 profile cylinder, it serves as a drop-in replacement for other ISO 15552 cylinders, sharing identical mounting interfaces and accessories like FA front flanges or TC trunnions. Remember that the adjustable air cushion only decelerates the piston near stroke end; it is not a locking device. If your process must hold a load vertically without live air pressure, you must integrate a BSE rod lock or an external pilot-operated check valve.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE80 Standard Cylinder SE80AX100 FAQ
At 0.5 MPa, this 80 mm bore cylinder provides 2513 N of push force and 2268 N of pull force. At 0.7 MPa, the push force increases to 3518 N. The absolute maximum push capacity is 513 kgf when operated at the 1.0 MPa pressure limit.
It is dimensionally interchangeable per ISO 15552, meaning it shares standard mounting footprints with other ISO 15552 profile cylinders. This specific SKU does not include a position sensing magnet, so it cannot host CMSE or DMSE electronic switches without modification.
