Airtac SIJ100 Double Rod Adjustable Cylinder SIJ100X100-10S
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
1. ISO15552 (formerly ISO6431) compliant standard cylinder design;
2. Piston utilizes dual Y-shaped bidirectional seals with self-compensating functionality, delivering extended service life and low dynamic friction;
3. Hexagonal tie rod configuration enhances structural stability with superior corrosion resistance;
4. Optimized cylinder structure ensures smooth stroke operation;
5. Multiple cylinder specifications and mounting accessories available for customized applications.
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ100
AirTAC SIJ100X100-10S Double Rod Adjustable Cylinder Specifications
- Model Code: SIJ100X100-10S
- Type: Double rod cylinder with adjustable stroke
- Bore Size: Ø100 mm
- Stroke: 100 mm (adjustable through ±5° rotation)
- Operating Pressure: 0.1-0.9 MPa
- Piston Rod Diameter: Ø25 mm (hard chrome-plated steel)
- Cushioning: Adjustable rubber buffers on both ends
- Port Size: PT1/4 (G1/4 optional)
- Ambient Temperature: -20℃ to +80℃
- Seal Material: Nitrile Butadiene Rubber (NBR)
- Tube Material: Anodized aluminum alloy
- Mounting Style: Front flange with positioning holes (ISO 15552 standard)
- Weight: 12.7 kg ±3%
- Dimensions (L×W×H):
- Extended Length: 438 mm (stroke 100mm)
- Body Width: 140 mm (between rod centers)
- Height with Mounts: 195 mm
- Repeat Positioning Accuracy: ±0.5 mm
- IP Rating: IP65 (standard wipers)
High-rigidity twin rod cylinder featuring a unique 360° adjustable stroke mechanism through rotating end caps. The chrome-plated piston rods and precision honed tube ensure smooth operation under heavy lateral loads. Integrated magnet slots allow for sensor mounting without external brackets. Special anti-rotation design maintains parallel rod alignment during operation.
- Precision press machine tooling alignment systems
- Automated pallet clamping/unclamping mechanisms
- Vertical lift gates in automotive assembly lines
- Paper roll tensioning systems in printing presses
- Glass panel flipping mechanisms
Installation Guidance:
Use M10x1.5 mounting bolts (Grade 8.8 or higher) with Loctite 243.
Maintain 0.5-1mm clearance between rods and adjacent components.
Lubricate with ISO VG32 hydraulic oil before initial operation.
Do NOT exceed 1.2 MPa pressure during adjustment.
Always lock adjustment screws with 3.5 N·m torque after stroke setting.
| Property | Property Value |
|---|---|
| sku | SIJ100X100-10S |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | S-Magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
