Airtac SIJ100 Double Rod Adjustable Cylinder SIJ100X100-50
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
1. ISO15552 (formerly ISO6431) compliant standard cylinder design;
2. Piston utilizes dual Y-shaped bidirectional seals with self-compensating functionality, delivering extended service life and low dynamic friction;
3. Hexagonal tie rod configuration enhances structural stability with superior corrosion resistance;
4. Optimized cylinder structure ensures smooth stroke operation;
5. Multiple cylinder specifications and mounting accessories available for customized applications.
Category: Adjustable Cylinders, Brand: AIRTAC, Series: SIJ100
AirTAC SIJ100X100-50 Dual Axis Adjustable Cylinder Technical Profile
- Full model designation: SIJ100X100-50
- Cylinder type: Double rod adjustable stroke (mechanical stopper type)
- Bore size: Φ100mm ±0.1mm tolerance
- Maximum stroke: 100mm (adjustable through 5mm increment spacers)
- Operating pressure range: 0.05-1.0 MPa (vacuum to 10 bar)
- Ambient temperature: -20℃ to 80℃ (dry air required below 0℃)
- Cushioning: Adjustable elastic buffer + shock absorber pad
- Mounting style: Basic type (axial foot mounting with 4×M8 threaded holes)
- Port size: G3/8 (BSPP) with 12mm push-in fittings
- Piston rod material: Chrome-plated SCM435 steel (HRC 50-55)
- Seal type: HNBR seals with wear-resistant guide rings
- Weight: 8.6kg ±2% (without accessories)
- Dimensions: 352mm(L) × 128mm(W) × 128mm(H) (full extension)
- Rod diameter: Φ25mm double rods (chrome-plated)
- Lubrication: Pre-lubricated (relubrication interval: 3,000km stroke)
- ISO certification: Compliant with ISO 15552 standard
High-precision dual rod cylinder featuring micrometer-grade position repeatability (±0.2mm). The symmetrical rod configuration eliminates lateral torque, making it ideal for precision alignment tasks. Includes stroke adjustment mechanism with positive mechanical locks and integrated shock absorption for high-cycle applications. Corrosion-resistant construction with IP54 rating for industrial environments.
- Automated welding fixture positioning systems
- Die casting machine core-pulling mechanisms
- Glass tempering furnace door actuators
- Automotive wheel alignment test rigs
- Pharmaceutical blister packaging presses
Installation guidelines:
Maintain parallel alignment within 0.2mm/m using precision levels during mounting.
For vertical installations, use mandatory rod-end support brackets (sold separately).
Allow 15mm thermal expansion clearance at mounting points.
| Property | Property Value |
|---|---|
| sku | SIJ100X100-50 |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT 1/2 |
| Magnet | Non-magnetic |
| Bore Diameter | 100mm |
| Stroke | 100mm |
