Airtac SIJ63 Double Rod Adjustable Cylinder SIJ63X100-40S
A cropped merino wool cardigan taken up a notch, thanks to the flecks of metallic thread throughout. We love it even more paired with the matching sweater-pants.
2. Dual Y-shaped axial seals on piston for automatic wear compensation, extended service life, and low friction coefficient
3. Crisscross pattern reinforced cylinder tube with stainless steel tie rods, delivering superior corrosion resistance
4. Precisely adjustable cushioning mechanism ensures smooth stroke operation
5. Customizable with multiple stroke lengths and compatible mounting accessories for flexible system integration
Category: Adjustable Cylinders | Brand: Airtac | Series: SIJ63
AirTAC SIJ63X100-40S Dual Axis Adjustable Cylinder Specifications
- Model: SIJ63X100-40S
- Type: Double rod adjustable stroke cylinder
- Bore size: 63 mm
- Stroke: 100 mm (adjustable)
- Operating pressure: 0.15–0.8 MPa
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting style: Basic foot mounting (MF1) with optional side mounting brackets
- Port size: M5x0.8 (G1/8 equivalent)
- Rod material: Hard chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 2.5 kg ±3%
- Dimensions:
- Total length (L): 202 mm (including rods)
- Body width (W): 80 mm (mounting face to rear)
- Height (H): 63 mm (excluding mounting hardware)
- Rod diameter: 16 mm (per rod)
- Center-to-center rod spacing: 50 mm
- ISO standard: 15552 compliant
- Protection rating: IP54 (standard wipers)
High-precision dual rod cylinder featuring micron-level positioning repeatability (±0.1mm) through its rigid dual-axis design. The 40S variant includes pre-drilled lateral mounting holes and reinforced end caps for vibration resistance. Optimized for vertical installations with asymmetric loads, it supports manual stroke adjustment via mechanical stops.
- Precision clamping fixtures in CNC machining centers
- Vertical lifting mechanisms for assembly robots
- Parallel motion systems in glass handling equipment
- Positioning stages for optical component manufacturing
- Packaging line product height adjustment stations
Installation guidelines:
- Align rods within 0.05mm/m parallelism tolerance
- Use M6x1 mounting screws with 12.9 grade minimum
- Apply anti-vibration compound on adjustable stoppers
- Lubricate with ISO VG32 hydraulic oil if operating below 1 Hz
| Property | Property Value |
|---|---|
| sku | SIJ63X100-40S |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20℃ to 80℃ Speed Range: 30-800 mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 63mm |
| Stroke | 100mm |
