AirTAC SE Series · ISO 15552 Cylinder

Airtac SE63 Standard Cylinder SE63X75

The AirTAC SE63 Standard Cylinder SE63X75 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø63mm bore and 75mm stroke, PT3/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ63 mm
  • Stroke75 mm
  • Port sizePT3/8
  • Acting typeDouble acting
  • Rod threadM16×1.5
  • CushionAdjustable, 36 mm
$81.38 $88.88Save 8% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SE63 stroke, mounting and version on one page All SE63 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SE63 Standard Cylinder SE63X75

The AirTAC SE63X75 is a double-acting single-rod ISO 15552 profile cylinder engineered to deliver a 1559 N push force at 0.5 MPa. Driven by a 63 mm bore, it provides a 75 mm stroke and utilizes a PT3/8 port to efficiently manage compressed air for both extension and retraction cycles.

Built with an extruded aluminum barrel that omits external tie rods, the square body resists corrosion and mounts flush against machine frames. The field-adjustable pneumatic cushioning at both stroke ends allows technicians to tune end-stop deceleration via a set screw, softening impacts during high-speed 30-800 mm/s operations. This specific SKU lacks a built-in magnet, so it does not support CMSE or DMSE position sensing without modification.

Airtac SE63 Standard Cylinder SE63X75 Technical Specifications

ModelAirtac SE63 Standard Cylinder SE63X75
SeriesSE ISO 15552 profile cylinder
Bore sizeØ63 mm
Stroke75 mm
Acting typeDouble acting
Port sizePT3/8
Rod threadM16×1.5
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 36 mm
Max strokeUp to 1500 mm

Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø63mm)

PressurePush forcePull force
0.5 MPa1559 N1402 N
0.7 MPa2182 N—
Max (@1.0 MPa)318 kgf

Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SE63 Standard Cylinder SE63X75

SEISO 15552 / VDMA 24562 profile-barrel double-acting cylinder.
63Bore size in mm.
×75Stroke length in mm.
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).

Where the Airtac SE63 Standard Cylinder SE63X75 Is Used

precision_manufacturing

CNC Fixture Clamping

Uses the 1559 N extend force to secure heavy cast iron blocks during high-speed machining operations.

packaging

Pallet Dispenser Pusher

Deploys the 75 mm stroke to index empty wooden pallets into a high-speed packaging line.

factory

Stamping Press Ejector

Retracts with 1402 N of pull force to knock stamped sheet metal parts clear of a die.

Is the Airtac SE63 Standard Cylinder SE63X75 the Right Cylinder?

When sizing this 63 mm bore actuator, compare its 1559 N push at 0.5 MPa against the 50 mm bore (982 N) for lighter duties, or step up to the 80 mm bore (2513 N) if your payload demands higher thrust. Because this is a standard double-acting cylinder, it will drift if air pressure is lost or the valve centers; applications requiring strict load holding without live pressure need a BSE rod lock variant or an external pilot-operated check valve.

For retrofitting, this SE63X75 is dimensionally interchangeable per ISO 15552 standards, allowing a direct replacement for other ISO 15552 profile cylinders while utilizing the standardized 63 mm bore, 75 mm stroke, PT3/8 port, and standard mounting accessories. The 20 mm piston rod and M16x1.5 thread provide robust resistance to side loading, though any unsupported length over 300 mm still requires an external guide.

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SE63 Standard Cylinder SE63X75 FAQ

At 0.5 MPa, the 63 mm bore provides 1559 N of push force and 1402 N of pull force. At 0.7 MPa, push increases to 2182 N, with a maximum push capacity of 318 kgf at 1.0 MPa. The operational speed range is 30-800 mm/s.

Yes, the SE63X75 is dimensionally interchangeable per ISO 15552 standards, meaning it shares the exact mounting footprint, 75 mm stroke, and PT3/8 port sizes of other profile cylinders in this bore class for direct retrofitting.
