Airtac SE32 Standard Cylinder SE32AX150S
The AirTAC Airtac SE32 Standard Cylinder SE32AX150S is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø32mm bore and 150mm stroke, PT1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ32 mm
- Stroke150 mm
- Port sizePT1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
About the Airtac SE32 Standard Cylinder SE32AX150S
The AirTAC SE32AX150S is a double-acting, single-rod ISO 15552 profile cylinder engineered for precise linear motion. It features a 32mm bore and a 150mm stroke, generating 402N of push force at 0.5 MPa. This variant includes a SUS420J2 stainless steel piston rod (code A), making it highly suitable for environments where corrosion resistance and washdown durability are required. The extruded aluminum barrel lacks external tie rods, yielding a compact footprint that mounts flush against machine frames.
This unit comes equipped with a built-in magnet (code S) for position sensing, designed to integrate seamlessly with AirTAC CMSE reed and DMSE electronic switches. Field-adjustable pneumatic cushioning at both ends allows technicians to fine-tune end-of-stroke deceleration via a set screw, softening hard mechanical impacts during high-speed cycling. Operating at speeds of 30-800 mm/s, it uses a PT1/8 port and an M10x1.25 rod thread.
Airtac SE32 Standard Cylinder SE32AX150S Technical Specifications
| Model | Airtac SE32 Standard Cylinder SE32AX150S |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 150 mm |
| Acting type | Double acting |
| Port size | PT1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE32 Standard Cylinder SE32AX150S
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 32 | Bore size in mm. |
| ×150 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE32 Standard Cylinder SE32AX150S Is Used
Laboratory Dispenser
Drives a precision pump head for chemical reagents, utilizing the 402N push force and SUS420J2 stainless rod to withstand corrosive fluid splashing during washdown cycles.
Pouch Sealing Clamp
Actuates a sealing jaw on a vertical form-fill-seal machine, where the 150mm stroke provides the exact travel needed and the adjustable cushion prevents jarring at cycle end.
PCB Router Gate
Indexes a routing gate on an electronics assembly line, using the integrated magnet with DMSE solid-state sensors to confirm gate position at 30-800 mm/s speeds.
Is the Airtac SE32 Standard Cylinder SE32AX150S the Right Cylinder?
When sizing this 32mm bore actuator, evaluate your force margins carefully: the SE32AX150S provides 402N push and 345N pull at 0.5 MPa. If your application requires less force and a smaller footprint, the neighboring 25mm bore class is unavailable in the SE series, making this the most compact option. If you need substantially more thrust, stepping up to the 40mm bore yields 628N push at 0.5 MPa. Because this is a double-acting cylinder, it does not hold its load when air pressure is removed or a valve is centered; if your process demands fail-safe position holding, consider pairing it with an external pilot-operated check valve or utilizing the BSE rod lock variant.
For ISO 15552 dimensional interchangeability, you can specify this exact configuration—32mm bore, 150mm stroke, PT1/8 port, SUS420J2 rod, and an S magnet—using standard mounting accessories like LB foot brackets or FA front flanges. At 150mm stroke, the 12mm diameter rod and M10x1.25 thread handle moderate side loads adequately, though any long unsupported stroke exceeding 300mm would necessitate an external guide to prevent rod-bearing bending.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE32 Standard Cylinder SE32AX150S FAQ
The SE32AX150S delivers 402N push and 345N pull at 0.5 MPa, 563N push at 0.7 MPa, and a maximum push of 82 kgf at 1.0 MPa. It operates at a speed range of 30-800 mm/s.
Yes, the SE32AX150S is dimensionally interchangeable per ISO 15552 standards. You can use it as a drop-in replacement for other ISO 15552 profile cylinders, utilizing standard mounting hardware without modifying your machine frame.
