Airtac SE32 Standard Cylinder SE32AX200S
The AirTAC SE32 Standard Cylinder SE32AX200S is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø32mm bore and 200mm stroke, PT1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ32 mm
- Stroke200 mm
- Port sizePT1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SE32 Standard Cylinder SE32AX200S
The AirTAC SE32AX200S is a double-acting, single-rod ISO 15552 profile cylinder engineered for compact pneumatic tasks. It features a 32 mm bore and a 200 mm stroke, delivering 402 N of push force at 0.5 MPa and up to 82 kgf at 1.0 MPa. The extruded aluminum barrel design omits external tie rods, yielding a smooth, corrosion-resistant body that mounts flush in tight machine envelopes.
This configuration integrates a SUS420J2 stainless steel rod (code A) for washdown and corrosive environments. The built-in magnet (code S) enables precise position detection using AirTAC CMSE reed or DMSE electronic sensors. Field-adjustable air cushions at both ends allow you to tune end-of-stroke deceleration, protecting payloads from harsh mechanical impacts.
Airtac SE32 Standard Cylinder SE32AX200S Technical Specifications
| Model | Airtac SE32 Standard Cylinder SE32AX200S |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 200 mm |
| Acting type | Double acting |
| Port size | PT1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE32 Standard Cylinder SE32AX200S
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 32 | Bore size in mm. |
| ×200 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE32 Standard Cylinder SE32AX200S Is Used
Lab Diagnostic Centrifuge Loader
Uses the 402 N push force and SUS420J2 stainless rod to safely index and latch centrifuge doors in humid, sterilized laboratory environments.
Small PCB Conveyor Divert Gate
Employs the built-in magnet with DMSE sensors to time 200 mm diverting strokes on electronics assembly lines, fitting neatly within tight machine profiles.
Pouch Sealing Clamp Mechanism
Leverages the field-adjustable air cushion to softly seal food packaging without crushing delicate film edges at the end of the 200 mm extension.
Is the Airtac SE32 Standard Cylinder SE32AX200S the Right Cylinder?
Selecting the SE32AX200S is optimal when your application requires 402 N of push at 0.5 MPa. If you need less force, there is no smaller standard SE bore, so you would step up to the SE40X200, which offers 628 N of push at 0.5 MPa. As a standard ISO 15552 profile cylinder, it serves as a direct dimensional replacement for other ISO 15552 cylinders, sharing standardized mounting hardware. To match this exact unit, specify: 32 mm bore, 200 mm stroke, PT1/8 port, SUS420J2 rod, and the -S magnet. Since the stroke is 200 mm, ensure the unsupported rod bearing does not bend under heavy lateral loads; use an external guide rail for high offset weights. Note that the adjustable cushion only decelerates the piston near the stroke end and does not hold the load if air pressure is lost.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE32 Standard Cylinder SE32AX200S FAQ
At 0.5 MPa, this 32 mm bore cylinder provides 402 N of push and 345 N of pull force. At 0.7 MPa, the push force is 563 N. The maximum push force is 82 kgf at 1.0 MPa. It operates at a speed range of 30-800 mm/s.
No. The SE32AX200S is a standard double-acting cylinder and its adjustable air cushions only decelerate the piston near the end of the stroke; they do not lock or hold the load. If you need fail-safe position holding, consider a BSE series rod lock cylinder or an external pilot-operated check valve.
