Airtac SE32 Standard Cylinder SE32AX30SH
The AirTAC SE32 Standard Cylinder SE32AX30SH is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø32mm bore and 30mm stroke, PT1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ32 mm
- Stroke30 mm
- Port sizePT1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SE32 Standard Cylinder SE32AX30SH
The AirTAC SE32AX30SH is a double-acting single-rod ISO 15552 profile cylinder engineered for demanding environments. It delivers 402 N of push force at 0.5 MPa and operates within a 30-800 mm/s speed range. Featuring a SUS420J2 stainless steel rod and FKM Viton seals, this variant withstands corrosive washdowns and high temperatures up to 150 C.
Unlike traditional round-body or tie-rod actuators, its extruded aluminum barrel lacks external tie rods, yielding a compact, flush-mounting profile that resists debris buildup. The integrated -S magnet enables direct mounting of CMSE reed and DMSE electronic sensors into the body grooves, while field-adjustable air cushioning at both ends allows precise deceleration tuning to prevent hard end-stop impacts.
Airtac SE32 Standard Cylinder SE32AX30SH Technical Specifications
| Model | Airtac SE32 Standard Cylinder SE32AX30SH |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 30 mm |
| Acting type | Double acting |
| Port size | PT1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE32 Standard Cylinder SE32AX30SH
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 32 | Bore size in mm. |
| ×30 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE32 Standard Cylinder SE32AX30SH Is Used
Pharmaceutical Washdown
The SUS420J2 rod and 150 C FKM seals survive daily chemical washdowns on pill-pressing stations, providing reliable 402 N clamping.
PCB Router Gating
Uses the -S magnet with DMSE sensors to verify a 30 mm gate position on a circuit board routing spindle, ensuring debris is cleared.
Pouch Sealing Jaw
Adjustable end cushions soften the 30 mm stroke impact on high-speed medical pouch sealing jaws operating near 800 mm/s.
Is the Airtac SE32 Standard Cylinder SE32AX30SH the Right Cylinder?
For applications requiring less thrust, the adjacent SE25 bore is not standard in this series, so stepping down means exiting the ISO 15552 format; conversely, moving up to the SE40 bore provides 628 N push at 0.5 MPa if your payload increases. At 30 mm stroke, side-loading on the 12 mm rod is minimal, but always ensure the load is axially aligned to prevent premature seal wear. Because this is a standard ISO 15552 footprint with a PT1/8 port and basic mounting, it serves as a direct dimensional replacement for competing profile cylinders. Note that the adjustable cushion only decelerates the piston near stroke end and does not hold a load; if position holding without air pressure is required, consider the BSE rod-lock variant.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE32 Standard Cylinder SE32AX30SH FAQ
At 0.5 MPa, this 32 mm bore cylinder provides 402 N push and 345 N pull. At 0.7 MPa, the push force is 563 N, with a maximum push of 82 kgf at 1.0 MPa. Operating pressure is 0.15-1.0 MPa, and speed ranges from 30-800 mm/s.
Yes, the SE32AX30SH is dimensionally interchangeable per ISO 15552 standards, meaning it shares the exact same mounting footprint and PT1/8 port locations for direct retrofits, though you must use AirTAC CMSE or DMSE sensors for the -S magnet.
