Airtac SE32 Standard Cylinder SE32BX1000S
The AirTAC SE32 Standard Cylinder SE32BX1000S is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø32mm bore and 1000mm stroke, PT1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ32 mm
- Stroke1000 mm
- Port sizePT1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SE32 Standard Cylinder SE32BX1000S
The AirTAC SE32BX1000S is a double-acting, single-rod profile cylinder built to ISO 15552 / VDMA 24562 standards. It features a SUS304 stainless steel piston rod for superior corrosion resistance in washdown or chemically exposed environments. Delivering 402 N of push force at 0.5 MPa, this 32 mm bore unit is tailored for a 1000 mm non-standard stroke.
Its extruded aluminum barrel lacks external tie rods, yielding a compact, flush-mounting profile that simplifies sensor placement along three integrated grooves. The built-in magnet (-S) directly supports AirTAC CMSE reed and DMSE electronic position switches for precise end-of-travel detection.
Airtac SE32 Standard Cylinder SE32BX1000S Technical Specifications
| Model | Airtac SE32 Standard Cylinder SE32BX1000S |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 1000 mm |
| Acting type | Double acting |
| Port size | PT1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE32 Standard Cylinder SE32BX1000S
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 32 | Bore size in mm. |
| ×1000 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE32 Standard Cylinder SE32BX1000S Is Used
Lab Fluid Dispensing
The SUS304 rod withstands chemical splashes while driving a 1000 mm travel for automated reagent routing across multiple lab stations.
Bottling Line Transfer
Provides 402 N push at 0.5 MPa to index packaging trays through a washdown zone, utilizing the corrosion-resistant rod and CMSE sensor magnet.
Textile Guiding Frame
Extends a full meter to position fabric webs under tension, relying on adjustable end cushions to soften hard stops at high traverse speeds.
Is the Airtac SE32 Standard Cylinder SE32BX1000S the Right Cylinder?
At 0.5 MPa, this 32 mm bore generates 402 N push and 345 N pull. If your application requires less force, you can step down to the 25 mm bore, but stepping up to the 40 mm bore provides a stronger 628 N push for heavier guiding. Because the 1000 mm stroke exceeds the standard 32 mm maximum of 1000 mm, this is a made-to-order configuration.
For a 1000 mm stroke, the unsupported piston rod is highly susceptible to bending under side loads; an external linear guide is strongly recommended to prevent rod-bearing damage. As a standard ISO 15552 profile cylinder, it serves as a direct replacement for other ISO 15552 cylinders, matching the PT1/8 port and M10x1.25 rod thread. Remember, the field-adjustable air cushions only decelerate the piston near stroke end; a plain SE does not hold a load if air pressure is lost.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE32 Standard Cylinder SE32BX1000S FAQ
At 0.5 MPa, the 32 mm bore provides 402 N push and 345 N pull. At 0.7 MPa, push increases to 563 N, with a maximum push of 82 kgf at 1.0 MPa. The operating speed range is 30-800 mm/s.
Yes, it is dimensionally interchangeable per ISO 15552, matching the standard mounting footprint, PT1/8 port, and M10x1.25 rod thread. The built-in magnet also works seamlessly with AirTAC CMSE and DMSE sensors.
Authorized Export Seller
Genuine AirTAC parts produced by AirTAC factory.
1-Year Warranty
Covers non-human-caused product damage.
Fast Dispatch
Standard models are processed and dispatched in 3-5 business days.
Fast Reply
Most inquiries answered within 7-8 hours.
Request a Quote for Airtac SE32 Standard Cylinder SE32BX1000S
Send us the quantity and destination. We confirm price, stock and lead time — usually within 7-8 hours.
