Airtac SE32 Standard Cylinder SE32BX100S
The AirTAC Airtac SE32 Standard Cylinder SE32BX100S is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø32mm bore and 100mm stroke, PT1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ32 mm
- Stroke100 mm
- Port sizePT1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
About the Airtac SE32 Standard Cylinder SE32BX100S
The AirTAC SE32BX100S is a double-acting single-rod profile cylinder built to ISO 15552 standards, delivering a 402 N push at 0.5 MPa. Its square extruded aluminum barrel omits external tie rods, yielding a flush, corrosion-resistant body that simplifies mounting and reduces debris traps in tight machinery.
Equipped with a SUS304 stainless steel rod, this unit is configured for washdown and corrosive environments. The built-in magnet supports AirTAC CMSE reed and DMSE electronic sensors for precise end-position detection, while field-adjustable air cushioning at both ends softens end-of-stroke impacts.
Airtac SE32 Standard Cylinder SE32BX100S Technical Specifications
| Model | Airtac SE32 Standard Cylinder SE32BX100S |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | PT1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE32 Standard Cylinder SE32BX100S
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 32 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE32 Standard Cylinder SE32BX100S Is Used
Lab Dispenser Clamping
Secures small fluidic dispenser carriages with a precise 402 N force, utilizing the SUS304 rod to resist chemical exposure during reagent washdowns.
Pouch Sealing Jaws
Actuates lower sealing jaws on intermittent-motion pouch machines, where the 100 mm stroke provides rapid, compact cycling and the flush profile prevents film snagging.
PCB Pusher Assembly
Pushes printed circuit boards into test fixtures, relying on DMSE electronic sensors to confirm precise 100 mm extension without bouncing.
Is the Airtac SE32 Standard Cylinder SE32BX100S the Right Cylinder?
Choosing this 32 mm bore makes sense when your application requires roughly 400 N of extend force. If you need less power, there is no smaller ISO 15552 standard bore in this series, so you would look at compact ISO 21287 designs instead. If your load demands more thrust, stepping up to the 40 mm bore increases your 0.5 MPa push to 628 N. Because this is a 100 mm stroke, side-loading on the 12 mm rod is minimal, but always ensure the load is guided externally to prevent rod-bearing wear.
This cylinder serves as a drop-in dimensional replacement for any standard ISO 15552 cylinder, matching standard mounting patterns and PT1/8 ports. Note that the adjustable air cushion only decelerates the piston near stroke end; it will not hold a load if air pressure is lost. For position-holding safety, consider a BSE rod-lock variant.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE32 Standard Cylinder SE32BX100S FAQ
At 0.5 MPa, this 32 mm bore cylinder provides 402 N of push force and 345 N of pull force. At 0.7 MPa, the push force is 563 N, and the maximum push capacity is 82 kgf at 1.0 MPa. The operational speed range is 30-800 mm/s.
Yes, the SE32BX100S shares standard ISO 15552 mounting and port dimensions, allowing it to serve as a drop-in retrofit for any comparable 32 mm bore profile cylinder. Its PT1/8 port and standard M10x1.25 rod thread ensure mechanical compatibility with existing brackets.
