Airtac SE32 Standard Cylinder SE32BX100SH
The AirTAC SE32 Standard Cylinder SE32BX100SH is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø32mm bore and 100mm stroke, PT1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ32 mm
- Stroke100 mm
- Port sizePT1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SE32 Standard Cylinder SE32BX100SH
The AirTAC SE32BX100SH is a double-acting single-rod ISO 15552 profile cylinder engineered for demanding environments. It features a SUS304 stainless steel rod and FKM Viton seals, expanding the operating temperature range up to 150 C for washdown or high-heat duties. Delivering a robust 402 N push force at 0.5 MPa, this 32 mm bore unit is built for reliable actuation.
Its square extruded aluminum barrel eliminates external tie rods, yielding a compact footprint that mounts flush and resists corrosion. The integrated magnet (-S) directly supports AirTAC CMSE reed and DMSE electronic position sensing, while the field-adjustable air cushioning at both ends allows you to dial in end-of-stroke deceleration for smooth cycling.
Airtac SE32 Standard Cylinder SE32BX100SH Technical Specifications
| Model | Airtac SE32 Standard Cylinder SE32BX100SH |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | PT1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE32 Standard Cylinder SE32BX100SH
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 32 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE32 Standard Cylinder SE32BX100SH Is Used
Lab Bottle Capping
Provides precise 402 N downward clamping force at 0.5 MPa to seal pharmaceutical vials, with the FKM seal resisting thermal sterilization cycles up to 150 C.
Food Pouch Folding
Actuates packaging flap folders on a washdown line, where the SUS304 rod prevents corrosion during daily caustic cleaning and the -S magnet tracks cycle counts.
Small Part Ejection
Pushes lightweight plastic injection-molded parts out of a warm mold cavity, using adjustable pneumatic cushions to prevent scuffing the product at the end of the 100 mm stroke.
Is the Airtac SE32 Standard Cylinder SE32BX100SH the Right Cylinder?
Selecting this 32 mm bore cylinder makes sense when your application requires 402 N push at 0.5 MPa within a compact ISO 15552 envelope. If you need less force, there is no smaller standard SE bore, so you would look outside the series; if you need more power, stepping up to the 40 mm bore yields 628 N push at 0.5 MPa. Because the standard SE lacks a locking mechanism, the piston will drift if air pressure is lost or the valve is centered—use a BSE rod lock variant if you must hold a load safely without live pressure.
As a dimensionally interchangeable ISO 15552 cylinder, it serves as a direct replacement for other standard profile cylinders, utilizing the same PT1/8 port and M10x1.25 rod thread. The 100 mm stroke keeps the Ø12 mm rod well-supported, but for any stroke over 300 mm you should add an external guide to prevent rod-bearing bending under side loads.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE32 Standard Cylinder SE32BX100SH FAQ
At 0.5 MPa it provides 402 N push and 345 N pull. At 0.7 MPa the push increases to 563 N. The maximum push force is 82 kgf when operated at the 1.0 MPa pressure limit.
Yes, its standardized ISO 15552 mounting dimensions make it a direct replacement for other profile cylinders. However, it is a standard double-acting cylinder, not a rod lock; it cannot hold a load without air pressure and will drift if the valve is centered.
