Airtac SE32 Standard Cylinder SE32BX150S
The AirTAC SE32 Standard Cylinder SE32BX150S is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø32mm bore and 150mm stroke, PT1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ32 mm
- Stroke150 mm
- Port sizePT1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SE32 Standard Cylinder SE32BX150S
The AirTAC SE32BX150S is a double-acting single-rod profile cylinder built to the ISO 15552 / VDMA 24562 standard. It features a 32mm bore and a 150mm stroke, generating 402 N of push force at 0.5 MPa. The square extruded aluminum barrel completely eliminates external tie rods, yielding a compact, corrosion-resistant body that mounts flush against machine frames while protecting internal mechanics.
This specific configuration utilizes a SUS304 stainless steel piston rod (code B) for superior resistance in corrosive or washdown environments. Equipped with a built-in magnet (code S), it supports position sensing via AirTAC CMSE reed or DMSE electronic switches fitted into the sensor grooves on three sides of the body.
Airtac SE32 Standard Cylinder SE32BX150S Technical Specifications
| Model | Airtac SE32 Standard Cylinder SE32BX150S |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 150 mm |
| Acting type | Double acting |
| Port size | PT1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE32 Standard Cylinder SE32BX150S
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 32 | Bore size in mm. |
| ×150 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE32 Standard Cylinder SE32BX150S Is Used
Lab Diagnostic Dispensing
The SUS304 rod withstands chemical wipe-down, while the 402 N push force accurately actuates reagent dispensing heads on automated diagnostic analyzers.
Small Pouch Sealing Jaws
Uses the 150mm stroke to close PTFE-coated sealing bars on vertical form-fill machines, relying on adjustable end cushions to prevent jaw bounce.
PCB Router Gating
Shifts delicate sorting gates on SMT lines, using the integrated -S magnet with DMSE electronic sensors to verify gate position at 30-800 mm/s.
Is the Airtac SE32 Standard Cylinder SE32BX150S the Right Cylinder?
Delivering 402 N push at 0.5 MPa, this 32mm bore is the smallest standard size in the SE range. If you need less force, no smaller ISO 15552 bore exists in this series. If your application requires heavier thrust, stepping up to the 40mm bore yields 628 N push at 0.5 MPa. The standard PT1/8 port and 150mm stroke make this a direct dimensional direct replacement for any ISO 15552 cylinder footprint. Remember that an SE cylinder relies on live air pressure to hold a load; if pneumatic power is lost, the piston will drift and cannot maintain its position. For 150mm strokes, side loading is minimal, but always verify the rod bearing can handle any unintended guide loads.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE32 Standard Cylinder SE32BX150S FAQ
At 0.5 MPa, it provides 402 N push and 345 N pull. At 0.7 MPa, push increases to 563 N. The maximum push is 82 kgf at 1.0 MPa. Operating speed ranges from 30-800 mm/s.
Yes, the B code indicates a SUS304 stainless steel rod for corrosion resistance. It is dimensionally interchangeable with all ISO 15552 profile cylinders, sharing standard mounting interface dimensions without claiming brand equivalence.
