Airtac SE32 Standard Cylinder SE32BX160
The AirTAC SE32 Standard Cylinder SE32BX160 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø32mm bore and 160mm stroke, PT1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ32 mm
- Stroke160 mm
- Port sizePT1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SE32 Standard Cylinder SE32BX160
The AirTAC SE32BX160 is a double-acting single-rod ISO 15552 profile cylinder engineered for compact pneumatic actuation. It delivers 402 N of push force and 345 N of pull force at 0.5 MPa, peaking at 82 kgf maximum push at 1.0 MPa. The extruded aluminum barrel lacks external tie rods, yielding a flush, corrosion-resistant exterior that simplifies flush mounting in tight machine envelopes.
This specific configuration utilizes a SUS304 stainless steel piston rod (code B), making it highly suitable for corrosive environments or washdown duty. It features field-adjustable pneumatic cushioning at both ends to decelerate the payload smoothly near the stroke limits. Note that this SKU lacks a built-in magnet, meaning it is not wired for CMSE or DMSE position sensing out of the box.
Airtac SE32 Standard Cylinder SE32BX160 Technical Specifications
| Model | Airtac SE32 Standard Cylinder SE32BX160 |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 160 mm |
| Acting type | Double acting |
| Port size | PT1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE32 Standard Cylinder SE32BX160
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 32 | Bore size in mm. |
| ×160 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE32 Standard Cylinder SE32BX160 Is Used
Lab Diagnostic Equipment
The SUS304 rod withstands chemical wipe-downs, while the 402 N push force accurately positions sample trays in automated medical analyzers.
Small Pouch Sealing
Delivers precise 160 mm stroke actuation for sealing jaws, using its adjustable end cushions to prevent impact damage at high cycling speeds.
PCB Handling Gates
The tie-rod-free extruded profile mounts flush to conveyor frames, using 345 N pull force to pivot diverter arms for electronics assembly lines.
Is the Airtac SE32 Standard Cylinder SE32BX160 the Right Cylinder?
Select this 32 mm bore when your application requires 402 N push at 0.5 MPa but space precludes larger units. If you need less force, step down is not available as this is the smallest standard SE bore. If your load demands more force, stepping up to the 40 mm bore provides 628 N push at 0.5 MPa. The 160 mm stroke is well within the 1000 mm maximum standard stroke for this bore, keeping it a stock-compatible dimension.
Because this model has a 160 mm stroke, the 12 mm rod and M10x1.25 thread can handle moderate side loads, but any heavy off-center load still requires an external guide to prevent rod-bearing bending. Remember that a standard SE does not hold its position when air is lost or exhausted; the piston will drift. For load-holding requirements, consider the BSE rod-lock variant. As a true ISO 15552 cylinder, it is dimensionally interchangeable with other ISO 15552 profile cylinders, sharing standard mounting accessories like LB foot or FA front flange.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE32 Standard Cylinder SE32BX160 FAQ
At 0.5 MPa, this 32 mm bore cylinder provides 402 N push and 345 N pull. At 0.7 MPa, push increases to 563 N, with a maximum push of 82 kgf at 1.0 MPa. It uses a PT1/8 port, a 12 mm rod, and an M10x1.25 rod-end thread.
This specific SKU lacks the -S magnet, so it cannot host CMSE or DMSE sensors without modification. Dimensionally, it is built to the ISO 15552 standard, meaning it serves as a direct replacement for other ISO 15552 profile cylinders and shares standard mounting footprints.
