Airtac SE32 Standard Cylinder SE32BX175S
The AirTAC SE32 Standard Cylinder SE32BX175S is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø32mm bore and 175mm stroke, PT1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ32 mm
- Stroke175 mm
- Port sizePT1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SE32 Standard Cylinder SE32BX175S
The AirTAC SE32BX175S is a double-acting single-rod ISO 15552 profile cylinder engineered for precise linear motion. It delivers a push force of 402 N at 0.5 MPa, making it well-suited for compact actuation tasks requiring a 175 mm stroke. The square extruded aluminum barrel omits external tie rods, yielding a flush, corrosion-resistant body that simplifies mounting and reduces debris traps.
This configuration features a SUS304 stainless steel rod (code B) for superior resistance in corrosive or washdown environments. A built-in magnet (code S) enables position detection using AirTAC CMSE reed or DMSE electronic sensors. The field-adjustable air cushioning at both ends allows technicians to tune end-of-stroke deceleration, preventing harsh impacts during high-speed cycling.
Airtac SE32 Standard Cylinder SE32BX175S Technical Specifications
| Model | Airtac SE32 Standard Cylinder SE32BX175S |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 175 mm |
| Acting type | Double acting |
| Port size | PT1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE32 Standard Cylinder SE32BX175S
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 32 | Bore size in mm. |
| ×175 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE32 Standard Cylinder SE32BX175S Is Used
Lab Diagnostic Dispenser
Actuates reagent pipetting heads in sterile enclosures, leveraging the 402 N push force and SUS304 rod to withstand daily chemical washdowns without pitting.
Pouch Sealing Press
Drives the upper sealing jaw through a 175 mm stroke, using the adjustable end cushions to soften the crimp impact and prevent packaging film tearing.
PCB Router Gate
Indexes a safety guard on a circuit board routing station, utilizing the built-in magnet to trigger DMSE electronic sensors for precise closed-loop positioning.
Is the Airtac SE32 Standard Cylinder SE32BX175S the Right Cylinder?
Selecting the SE32BX175S is optimal when your application requires a compact 32 mm bore generating 402 N of push at 0.5 MPa. If you need less force, the next size down is unavailable in this standard ISO 15552 range, making 32 mm the baseline. If your load demands more thrust, stepping up to the 40 mm bore increases push to 628 N at 0.5 MPa. Because this is a double-acting cylinder, it will drift if air pressure is lost or the valve is centered; it cannot hold a load statically without live pressure or an external rod lock like the BSE series.
With a 175 mm stroke, the 12 mm rod and M10x1.25 thread provide a robust interface, though long unsupported strokes still necessitate an external guide to prevent rod-bearing bending. This model is dimensionally interchangeable per ISO 15552, serving as a direct replacement for other ISO 15552 cylinders without altering mounting hardware. It uses a PT1/8 port and includes the -S magnet for standard sensor integration.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE32 Standard Cylinder SE32BX175S FAQ
At 0.5 MPa, this 32 mm bore cylinder provides 402 N of push and 345 N of pull. At 0.7 MPa, the push increases to 563 N. The maximum push capacity is 82 kgf at 1.0 MPa, and it operates at speeds between 30 and 800 mm/s.
Yes, the SE32BX175S is dimensionally interchangeable per ISO 15552. You can use it as a direct replacement for other ISO 15552 profile cylinders by matching the 32 mm bore, 175 mm stroke, PT1/8 port, and your existing mounting accessories.
