Airtac SE32 Standard Cylinder SE32BX200S
The AirTAC SE32 Standard Cylinder SE32BX200S is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø32mm bore and 200mm stroke, PT1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ32 mm
- Stroke200 mm
- Port sizePT1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SE32 Standard Cylinder SE32BX200S
The AirTAC SE32BX200S is a double-acting single-rod profile cylinder built to the ISO 15552 standard. It features a 32 mm bore and a 200 mm stroke, generating 402 N of push force at 0.5 MPa. The square extruded aluminum barrel omits external tie rods, yielding a compact footprint that mounts flush against machine frames while resisting corrosion.
Equipped with a SUS304 stainless steel piston rod (option B), this unit is purpose-built for washdown and corrosive environments. The integrated position magnet (option S) interfaces directly with AirTAC CMSE reed and DMSE electronic sensors, while field-adjustable air cushions at both ends soften end-of-stroke impacts.
Airtac SE32 Standard Cylinder SE32BX200S Technical Specifications
| Model | Airtac SE32 Standard Cylinder SE32BX200S |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 200 mm |
| Acting type | Double acting |
| Port size | PT1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE32 Standard Cylinder SE32BX200S
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 32 | Bore size in mm. |
| ×200 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE32 Standard Cylinder SE32BX200S Is Used
Lab Diagnostic Diverters
Actuates routing gates on sample analyzers where the SUS304 rod withstands chemical splashes and the 402 N force securely flips fluid paths.
Packaging Reject Arms
Pushes misaligned cartons off a processing line using a 200 mm stroke, relying on CMSE sensors to verify full extension before reset.
Small Parts Forming
Drives light-duty bending jigs for electrical contacts, utilizing the adjustable end cushions to prevent mark-through on delicate metals.
Is the Airtac SE32 Standard Cylinder SE32BX200S the Right Cylinder?
This 32 mm bore provides 402 N push at 0.5 MPa; if your application requires less force, the neighbouring 40 mm bore steps up to 628 N. Because the 200 mm stroke creates an extended lever arm on the 12 mm rod, external guiding is recommended to prevent side-load bearing wear. As a dimensionally interchangeable ISO 15552 cylinder, it drops directly into existing foot, flange, or trunnion hardware using PT1/8 ports.
Note that the adjustable pneumatic cushioning only decelerates the piston near stroke end and does not hold the load. If air pressure is lost, the cylinder will drift; for position holding, consider a BSE rod lock variant.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE32 Standard Cylinder SE32BX200S FAQ
At 0.5 MPa, the push force is 402 N and the pull force is 345 N. At 0.7 MPa, the push force is 563 N. The maximum push force is 82 kgf at 1.0 MPa.
Yes. The SE32BX200S shares standard ISO 15552 mounting dimensions, allowing it to drop into existing machinery. It uses a PT1/8 port and accepts standard AirTAC CMSE and DMSE sensors via its integrated magnet.
