Airtac SE32 Standard Cylinder SE32BX220S
The AirTAC SE32 Standard Cylinder SE32BX220S is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø32mm bore and 220mm stroke, PT1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ32 mm
- Stroke220 mm
- Port sizePT1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SE32 Standard Cylinder SE32BX220S
The AirTAC SE32BX220S is a double-acting single-rod ISO 15552 profile cylinder engineered for precise linear motion in compact spaces. Operating at 0.5 MPa, it delivers 402 N of push force and 345 N of pull force, making it well-suited for light-duty actuation. The unit features a SUS304 stainless steel piston rod (option B) specifically chosen for corrosive environments or washdown duty.
This model includes a built-in magnet (option S) for position sensing via AirTAC CMSE reed or DMSE electronic switches. The square extruded aluminum barrel eliminates external tie rods, yielding a flush profile that simplifies mounting and reduces trapped debris. Furthermore, the field-adjustable pneumatic cushioning at both ends allows technicians to tune end-of-stroke deceleration, softening hard impacts during high-speed cycling.
Airtac SE32 Standard Cylinder SE32BX220S Technical Specifications
| Model | Airtac SE32 Standard Cylinder SE32BX220S |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 220 mm |
| Acting type | Double acting |
| Port size | PT1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE32 Standard Cylinder SE32BX220S
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 32 | Bore size in mm. |
| ×220 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE32 Standard Cylinder SE32BX220S Is Used
Lab Diagnostic Centrifuge Loading
Utilizes the 402 N push force and SUS304 rod to index sample racks into a sealed centrifuge chamber, resisting chemical splashes during frequent washdown cycles.
Pouch Filling Nozzle Diverter
Employs the 220 mm stroke to actuate a deflector gate on a vertical form-fill-seal machine, using the built-in magnet to confirm gate position via DMSE sensors.
Small Parts Sorting Ejector
Leverages the compact 32 mm profile barrel and adjustable end cushions to rapidly eject misaligned plastic caps from a vibratory bowl feeder without damaging the components.
Is the Airtac SE32 Standard Cylinder SE32BX220S the Right Cylinder?
When sizing this 32 mm bore actuator, compare its 402 N push at 0.5 MPa against your actual load requirements. If your application demands less force, stepping down is not an option as 32 mm is the smallest standard SE bore. If you need significantly more power, stepping up to the 40 mm bore provides 628 N of push at 0.5 MPa. Because this cylinder features a 220 mm stroke, the 12 mm rod and internal bearing face bending moments under heavy lateral loads; always incorporate an external guide rail to prevent premature seal wear.
As a true ISO 15552 profile cylinder, the SE32BX220S provides a direct replacement for other ISO 15552 cylinders, sharing identical mounting footprint dimensions. It uses a PT1/8 port and includes the -S magnet for CMSE / DMSE sensors. Remember that the adjustable air cushion only decelerates the piston near stroke end—it does not hold the load. If air pressure is lost, the rod will drift; for positive holding, consider the BSE rod lock variant.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE32 Standard Cylinder SE32BX220S FAQ
The SE32BX220S provides a push force of 402 N and a pull force of 345 N at 0.5 MPa. At 0.7 MPa, the push force increases to 563 N, with a maximum push capacity of 82 kgf at 1.0 MPa. The operational speed range is 30-800 mm/s.
Yes, the SE32BX220S is dimensionally interchangeable per ISO 15552 standards. You can use it as a direct replacement for other ISO 15552 profile cylinders with a 32 mm bore and 220 mm stroke, retaining your existing mounting hardware and PT1/8 port connections.
