Airtac SE32 Standard Cylinder SE32X250
The AirTAC Airtac SE32 Standard Cylinder SE32X250 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø32mm bore and 250mm stroke, PT1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it a drop-in replacement for other ISO 15552 cylinders in automation lines.
- BoreØ32 mm
- Stroke250 mm
- Port sizePT1/8
- Acting typeDouble acting
- Rod threadM10×1.25
- CushionAdjustable, 27 mm
About the Airtac SE32 Standard Cylinder SE32X250
The AirTAC SE32X250 is a double-acting, single-rod ISO 15552 profile cylinder engineered for compact pneumatics. It delivers a push force of 402 N at 0.5 MPa and 563 N at 0.7 MPa, retracting with 345 N. Featuring a 32 mm bore and 250 mm stroke, it uses a PT1/8 port and a 12 mm hard-chrome rod.
Its square extruded aluminum barrel eliminates external tie rods, yielding a flush, corrosion-resistant body that mounts cleanly in tight machine envelopes. The field-adjustable air cushion at both ends lets you dial out hard end-stops at speed, while the three-sided sensor grooves remain ready for future CMSE or DMSE switches if a magnet is later required.
Airtac SE32 Standard Cylinder SE32X250 Technical Specifications
| Model | Airtac SE32 Standard Cylinder SE32X250 |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø32 mm |
| Stroke | 250 mm |
| Acting type | Double acting |
| Port size | PT1/8 |
| Rod thread | M10×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 27 mm |
| Max stroke | Up to 1000 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø32mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 402 N | 346 N |
| 0.7 MPa | 563 N | — |
| Max (@1.0 MPa) | 82 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE32 Standard Cylinder SE32X250
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 32 | Bore size in mm. |
| ×250 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE32 Standard Cylinder SE32X250 Is Used
Carton Erecting Jaws
Provides the 402 N push force needed to fold and seal corrugated carton blanks at high cycling rates within packaging lines.
Package Divert Gate
Actuates a lightweight routing flap to sort small parcels on a conveyor belt, utilizing the 250 mm stroke to clear the lane.
Lab Sample Dispenser
Drives a 32 mm bore metering pump for precise reagent dosing, benefiting from the adjustable cushion to prevent fluid splashing.
Is the Airtac SE32 Standard Cylinder SE32X250 the Right Cylinder?
If you need less thrust, stepping down to the 25 mm bore drops the push force to roughly 247 N at 0.5 MPa, whereas moving up to the 40 mm bore increases it to 628 N. This SE32X250 lacks a built-in magnet, so it cannot host CMSE or DMSE position sensors without modification. As a true ISO 15552 profile cylinder, it serves as a drop-in dimensional replacement for other ISO 15552 cylinders, sharing standard mounting hardware. With a 250 mm stroke, the 12 mm rod is prone to bearing bending under side loads, so use an external guide for heavy or offset assemblies. Note that the air cushion only decelerates the piston; it does not hold a load if air pressure is lost.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE32 Standard Cylinder SE32X250 FAQ
The SE32X250 provides a push force of 402 N and a pull force of 345 N at 0.5 MPa. At 0.7 MPa, the push force is 563 N, with a maximum push of 82 kgf at 1.0 MPa. The operating speed range is 30-800 mm/s.
Yes, the SE32X250 is dimensionally interchangeable per ISO 15552 standards, meaning it shares the exact mounting footprint and hardware of other ISO 15552 profile cylinders. It is a drop-in retrofit option.
