AirTAC SE Series · ISO 15552 Cylinder

Airtac SE32 Standard Cylinder SE32X75

The AirTAC SE32 Standard Cylinder SE32X75 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø32mm bore and 75mm stroke, PT1/8 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ32 mm
  • Stroke75 mm
  • Port sizePT1/8
  • Acting typeDouble acting
  • Rod threadM10×1.25
  • CushionAdjustable, 27 mm
$49.33 $56.83Save 13% Standard model — usually dispatched in 3-5 days
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Shipped from our own warehouse: most standard models dispatch in 3–5 days; custom and non-standard models take 8–10 business days. Transit time after that depends on the destination.
Compare every SE32 stroke, mounting and version on one page All SE32 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7 h

About the Airtac SE32 Standard Cylinder SE32X75

The AirTAC SE32X75 is a double-acting, single-rod ISO 15552 profile cylinder engineered for compact pneumatics. It delivers a theoretical push force of 402 N at 0.5 MPa, making it well-suited for light-load routing and precise component positioning.

Its square extruded aluminum barrel eliminates external tie rods, yielding a flush exterior that resists corrosion and simplifies mounting flush against machine frames. The field-adjustable pneumatic cushioning at both stroke ends allows you to tune end-of-stroke deceleration, protecting payloads from harsh mechanical impacts.

Airtac SE32 Standard Cylinder SE32X75 Technical Specifications

ModelAirtac SE32 Standard Cylinder SE32X75
SeriesSE ISO 15552 profile cylinder
Bore sizeØ32 mm
Stroke75 mm
Acting typeDouble acting
Port sizePT1/8
Rod threadM10×1.25
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 27 mm
Max strokeUp to 1000 mm

Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø32mm)

PressurePush forcePull force
0.5 MPa402 N346 N
0.7 MPa563 N—
Max (@1.0 MPa)82 kgf

Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SE32 Standard Cylinder SE32X75

SEISO 15552 / VDMA 24562 profile-barrel double-acting cylinder.
32Bore size in mm.
×75Stroke length in mm.
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).

Where the Airtac SE32 Standard Cylinder SE32X75 Is Used

precision_manufacturing

PCB Drill Clamp

Provides 402 N of push force at 0.5 MPa to secure lightweight printed circuit boards within drilling fixtures without flexing the substrate.

packaging

Carton Flap Folder

Utilizes the 75 mm stroke to neatly tuck and fold small cardboard flaps on high-speed packaging lines, relying on the adjustable cushion to prevent tearing.

science

Lab Sample Dispenser

Actuates a 12mm rod to drive a metering valve for precise liquid reagent dispensing, benefiting from the smooth flush profile barrel.

Is the Airtac SE32 Standard Cylinder SE32X75 the Right Cylinder?

For tasks needing less force, the SE25 bore is unavailable in this ISO 15552 series, making the 32mm the starting point; stepping up to the SE40 bore provides a substantial 628 N push at 0.5 MPa for heavier lifting. This SE32X75 configuration uses a PT1/8 port, a 12mm rod with an M10x1.25 thread, and includes no built-in magnet, meaning position sensing is not available on this specific SKU. Because it is a standard double-acting cylinder, it will drift if air pressure is lost and cannot hold a load mid-stroke without a pilot-operated check valve or external rod lock.

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SE32 Standard Cylinder SE32X75 FAQ

The SE32X75 delivers a push force of 402 N and a pull force of 345 N at 0.5 MPa. At 0.7 MPa, the push force is 563 N, with a maximum push force of 82 kgf at 1.0 MPa. It operates between 0.15-1.0 MPa at speeds of 30-800 mm/s.

Yes, the SE32X75 is dimensionally interchangeable per ISO 15552 standards. You can use it as a direct replacement for other ISO 15552 profile cylinders, matching the 32mm bore, 75mm stroke, and PT1/8 porting without altering your mounting hardware.
