Airtac SE40 Standard Cylinder SE40AX200H
The AirTAC SE40 Standard Cylinder SE40AX200H is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø40mm bore and 200mm stroke, PT1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ40 mm
- Stroke200 mm
- Port sizePT1/4
- Acting typeDouble acting
- Rod threadM12×1.25
- CushionAdjustable, 30 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SE40 Standard Cylinder SE40AX200H
The AirTAC SE40AX200H is a double-acting single-rod ISO 15552 profile cylinder engineered for demanding environments. It delivers 628 N of push force and 528 N of pull force at 0.5 MPa, utilizing a 16 mm rod with an M12x1.25 thread. This configuration pairs a SUS420J2 stainless steel rod with a high-temperature FKM (Viton) seal, expanding the operating temperature range up to 150 C for washdown or heat-exposed machinery.
Built on an extruded aluminum barrel without external tie rods, the square profile provides flush mounting and integrates sensor grooves on three sides. The field-adjustable pneumatic cushioning at both ends allows you to tune end-of-stroke deceleration via a set screw, softening hard mechanical impacts during high-speed cycling up to 800 mm/s.
Airtac SE40 Standard Cylinder SE40AX200H Technical Specifications
| Model | Airtac SE40 Standard Cylinder SE40AX200H |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø40 mm |
| Stroke | 200 mm |
| Acting type | Double acting |
| Port size | PT1/4 |
| Rod thread | M12×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 30 mm |
| Max stroke | Up to 1200 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø40mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 628 N | 528 N |
| 0.7 MPa | 880 N | — |
| Max (@1.0 MPa) | 128 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE40 Standard Cylinder SE40AX200H
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 40 | Bore size in mm. |
| ×200 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE40 Standard Cylinder SE40AX200H Is Used
Flow Wrapper End Sealing
Drives the heated sealing jaws on continuous flow packaging lines, where the FKM Viton seal survives ambient heat radiating from the sealing bars while providing 628 N of precise clamping force.
Bottle Diverter Gate
Actuates stainless steel diverter arms on a washdown bottle conveyor, utilizing the SUS420J2 rod to resist moisture and caustic cleaning agents without pitting.
Lab Oven Door Actuator
Opens and closes heavy insulated doors on industrial laboratory ovens, functioning reliably in ambient temperatures up to 150 C where standard NBR or TPU seals would rapidly degrade.
Is the Airtac SE40 Standard Cylinder SE40AX200H the Right Cylinder?
If you need to step the bore down for a lighter duty cycle, the 32 mm version provides 402 N of push at 0.5 MPa. Conversely, moving up to the 50 mm bore yields 982 N of push at 0.5 MPa for heavier payloads. Because this specific SKU lacks the -S magnet, it will not support AirTAC CMSE or DMSE position sensors without a model change. As a true ISO 15552 cylinder, it serves as a dimensionally interchangeable direct replacement for any standard ISO 15552 mounting interface using the PT1/4 port. Furthermore, at a 200 mm stroke, the unsupported piston rod is susceptible to bending under lateral loads; always specify an external guide to prevent premature rod-bearing wear.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE40 Standard Cylinder SE40AX200H FAQ
This 40 mm bore cylinder generates 628 N push and 528 N pull at 0.5 MPa, 879 N push at 0.7 MPa, and a maximum push force of 128 kgf at 1.0 MPa. The operational speed range is 30-800 mm/s.
No, the SE40AX200H is a standard double-acting cylinder and the adjustable air cushions only decelerate the piston near stroke end; they are not a mechanical brake. If your application requires position holding without live air pressure, you must use a BSE series rod lock cylinder or an external pilot-operated check valve.
