AirTAC SE Series · ISO 15552 Cylinder

Airtac SE40 Standard Cylinder SE40X100

The AirTAC SE40 Standard Cylinder SE40X100 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø40mm bore and 100mm stroke, PT1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ40 mm
  • Stroke100 mm
  • Port sizePT1/4
  • Acting typeDouble acting
  • Rod threadM12×1.25
  • CushionAdjustable, 30 mm
$56.57 $64.07Save 11% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SE40 stroke, mounting and version on one page All SE40 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SE40 Standard Cylinder SE40X100

The AirTAC SE40X100 is a double-acting single-rod ISO 15552 profile cylinder engineered to deliver 628 N push force at 0.5 MPa. Its square extruded aluminum barrel eliminates external tie rods, yielding a compact footprint that mounts flush and resists corrosion while integrating seamlessly into standardized machinery.

This 40 mm bore unit features a 16 mm hard-chrome rod and a PT1/4 port, operating at speeds from 30-800 mm/s. Field-adjustable air cushioning at both ends allows you to tune end-of-stroke deceleration via a set screw, softening hard impacts during rapid cycling. This specific SKU ships without a sensor magnet, relying on external physical stops or limit switches for basic positioning.

Airtac SE40 Standard Cylinder SE40X100 Technical Specifications

ModelAirtac SE40 Standard Cylinder SE40X100
SeriesSE ISO 15552 profile cylinder
Bore sizeØ40 mm
Stroke100 mm
Acting typeDouble acting
Port sizePT1/4
Rod threadM12×1.25
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 30 mm
Max strokeUp to 1200 mm

Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø40mm)

PressurePush forcePull force
0.5 MPa628 N528 N
0.7 MPa880 N—
Max (@1.0 MPa)128 kgf

Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SE40 Standard Cylinder SE40X100

SEISO 15552 / VDMA 24562 profile-barrel double-acting cylinder.
40Bore size in mm.
×100Stroke length in mm.
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).

Where the Airtac SE40 Standard Cylinder SE40X100 Is Used

conveyor_belt

Package Diverting Gate

Actuates a routing flap on a packaging conveyor, utilizing the 628 N push force to smoothly pivot heavy cardboard cartons at high cycling speeds.

precision_manufacturing

CNC Chuck Ejection

Provides 100 mm of extended travel to push finished aluminum parts clear of a CNC lathe chuck, relying on adjustable cushioning to prevent damage to the workpiece.

packaging

Carton Flap Folding

Drives a mechanical folding arm on an automated carton sealer, where the 528 N retract force reliably pulls the mechanism back for the next cycle.

Is the Airtac SE40 Standard Cylinder SE40X100 the Right Cylinder?

Choosing this 40 mm bore makes sense when a 32 mm cylinder (402 N push at 0.5 MPa) lacks thrust, but a 50 mm bore (982 N push) would be physically oversized. The 100 mm stroke hits the sweet spot for compact ejection or lifting tasks. Because this is a double-acting cylinder, it will drift if air pressure is lost or the valve centers; applications requiring true load holding without live pressure should integrate an external pilot-operated check valve or step up to an AirTAC BSE rod-lock variant. As a true ISO 15552 profile cylinder, it serves as a direct replacement for any standard 40 mm bore, 100 mm stroke unit sharing the PT1/4 port and standardized mounting accessories.

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SE40 Standard Cylinder SE40X100 FAQ

At 0.5 MPa, the SE40X100 delivers 628 N of push (extend) force and 528 N of pull (retract) force. At 0.7 MPa, the push force increases to 879 N. The maximum push force is 128 kgf at 1.0 MPa. The operating speed ranges from 30-800 mm/s.

Yes. The SE40X100 is dimensionally interchangeable per ISO 15552 standards. You can use it as a direct replacement for other ISO 15552 profile cylinders with a 40 mm bore and 100 mm stroke, retaining your existing mounting hardware and PT1/4 pneumatic connections.
