AirTAC SE Series · ISO 15552 Cylinder

Airtac SE40 Standard Cylinder SE40X50

The AirTAC SE40 Standard Cylinder SE40X50 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø40mm bore and 50mm stroke, PT1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ40 mm
  • Stroke50 mm
  • Port sizePT1/4
  • Acting typeDouble acting
  • Rod threadM12×1.25
  • CushionAdjustable, 30 mm
$52.43 $59.93Save 12% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SE40 stroke, mounting and version on one page All SE40 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SE40 Standard Cylinder SE40X50

The AirTAC SE40X50 is a double-acting single-rod profile cylinder built to the ISO 15552 standard, delivering 628 N of push force at 0.5 MPa and a maximum of 128 kgf at 1.0 MPa. Its square extruded aluminum barrel eliminates external tie rods, yielding a compact footprint that mounts flush against machine frames while resisting corrosion.

This 40 mm bore unit features a 50 mm stroke, a PT1/4 port, and a 16 mm rod with an M12x1.25 thread. Field-adjustable air cushions at both ends allow you to tune end-of-stroke deceleration for fast 30-800 mm/s cycles. Because this specific SKU lacks the -S magnet suffix, it is not equipped for CMSE or DMSE position sensing out of the box.

Airtac SE40 Standard Cylinder SE40X50 Technical Specifications

ModelAirtac SE40 Standard Cylinder SE40X50
SeriesSE ISO 15552 profile cylinder
Bore sizeØ40 mm
Stroke50 mm
Acting typeDouble acting
Port sizePT1/4
Rod threadM12×1.25
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 30 mm
Max strokeUp to 1200 mm

Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø40mm)

PressurePush forcePull force
0.5 MPa628 N528 N
0.7 MPa880 N—
Max (@1.0 MPa)128 kgf

Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SE40 Standard Cylinder SE40X50

SEISO 15552 / VDMA 24562 profile-barrel double-acting cylinder.
40Bore size in mm.
×50Stroke length in mm.
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).

Where the Airtac SE40 Standard Cylinder SE40X50 Is Used

packaging

Carton Erector Flaps

Folds corrugated cardboard flaps on packaging lines using 628 N of push force, with adjustable cushions softening the impact during rapid 50 mm strokes.

conveyor_belt

Bottle Diverter Gate

Actuates routing gates on beverage conveyors where the tie-rod-free extruded profile prevents debris buildup and allows flush mounting.

precision_manufacturing

Small Part Clamp

Secures aluminum brackets in CNC machining fixtures, taking advantage of the 16 mm rod and M12x1.25 thread for stable clamping at 0.7 MPa.

Is the Airtac SE40 Standard Cylinder SE40X50 the Right Cylinder?

If you are sizing around this 628 N push class, stepping down to a 32 mm bore drops the 0.5 MPa push to 402 N, while stepping up to a 50 mm bore increases it to 982 N. As a true ISO 15552 cylinder, the SE40X50 is dimensionally interchangeable with other ISO 15552 cylinders for direct retrofits, utilizing standard mounting accessories like FA front flanges or LB foot brackets. Remember that the adjustable air cushion only decelerates the piston near stroke end; it is not a locking device, so loads will drift if air pressure is lost. To hold a load safely without live pressure, consider the BSE rod lock variant or an external pilot-operated check valve.

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SE40 Standard Cylinder SE40X50 FAQ

At 0.5 MPa, the SE40X50 provides 628 N of push force and 528 N of pull force. At 0.7 MPa, the push force is 879 N. The maximum push force is 128 kgf at 1.0 MPa. The operational speed range is 30-800 mm/s.

Yes, the SE40X50 is dimensionally interchangeable per ISO 15552 standards. It shares the same standardized mounting interface and PT1/4 port size, allowing it to serve as a direct replacement for other ISO 15552 profile cylinders using existing mounting hardware.
