AirTAC SE Series · ISO 15552 Cylinder

Airtac SE40 Standard Cylinder SE40X25

The AirTAC SE40 Standard Cylinder SE40X25 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø40mm bore and 25mm stroke, PT1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ40 mm
  • Stroke25 mm
  • Port sizePT1/4
  • Acting typeDouble acting
  • Rod threadM12×1.25
  • CushionAdjustable, 30 mm
$50.37 $57.87Save 12% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SE40 stroke, mounting and version on one page All SE40 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SE40 Standard Cylinder SE40X25

The AirTAC SE40X25 is a double-acting, single-rod ISO 15552 profile cylinder engineered for short-stroke automation. Operating at 0.5 MPa, it generates 628 N of push force and 528 N of pull force, scaling to 879 N push at 0.7 MPa. The extruded aluminum barrel design omits external tie rods, yielding a flush exterior that simplifies mounting and resists snagging in dense machinery layouts.

Field-adjustable pneumatic cushioning at both ends allows you to fine-tune end-of-stroke deceleration via a set screw, protecting internal components during rapid 25 mm transitions. This specific SKU is built without a position-sensing magnet, meaning it operates purely as an actuator without integrated CMSE or DMSE switch feedback.

Airtac SE40 Standard Cylinder SE40X25 Technical Specifications

ModelAirtac SE40 Standard Cylinder SE40X25
SeriesSE ISO 15552 profile cylinder
Bore sizeØ40 mm
Stroke25 mm
Acting typeDouble acting
Port sizePT1/4
Rod threadM12×1.25
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 30 mm
Max strokeUp to 1200 mm

Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø40mm)

PressurePush forcePull force
0.5 MPa628 N528 N
0.7 MPa880 N—
Max (@1.0 MPa)128 kgf

Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SE40 Standard Cylinder SE40X25

SEISO 15552 / VDMA 24562 profile-barrel double-acting cylinder.
40Bore size in mm.
×25Stroke length in mm.
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).

Where the Airtac SE40 Standard Cylinder SE40X25 Is Used

precision_manufacturing

Gripper Jaw Actuation

Drives short-stroke gripper jaws on collaborative robot arms, utilizing the 628 N push force at 0.5 MPa to firmly secure metal stampings during robotic transfer.

packaging

Flap Folding Mechanism

Powers the folding arm on an automated carton erector, relying on the 25 mm stroke and adjustable end cushions to snap cardboard flaps without bouncing.

sync_alt

Diverter Gate Control

Actuates a pneumatic diverter gate on a packaging conveyor, using the 16 mm rod to quickly pivot the deflector plate and reroute product flow.

Is the Airtac SE40 Standard Cylinder SE40X25 the Right Cylinder?

With a 25 mm stroke, the SE40X25 is optimized for short-travel actuation. If your application requires less force, stepping down to the 32 mm bore provides 402 N of push at 0.5 MPa. Conversely, if you need greater thrust, stepping up to the 50 mm bore yields 982 N of push at 0.5 MPa. Because this is a short stroke under 300 mm, side-load stress on the M12x1.25 rod thread is minimal, though external guides are always recommended for heavy radial loads.

As a true ISO 15552 profile cylinder, it serves as a direct replacement for other ISO 15552 cylinders, sharing identical mounting interface dimensions and PT1/4 port locations. Remember that a standard double-acting cylinder drifts when air is removed; if your process needs to hold a load mechanically without live pressure, consider the BSE rod-lock variant instead.

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SE40 Standard Cylinder SE40X25 FAQ

The SE40X25 generates 628 N push and 528 N pull at 0.5 MPa, and 879 N push at 0.7 MPa. It reaches a maximum push force of 128 kgf at its maximum operating pressure of 1.0 MPa.

Yes. The SE40X25 is dimensionally interchangeable per ISO 15552 standards, meaning it shares identical mounting interface dimensions and PT1/4 port locations with other ISO 15552 profile cylinders, allowing for a direct retrofit.
