The AirTAC SE40 Standard Cylinder SE40X200 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø40mm bore and 200mm stroke, PT1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
The AirTAC SE40X200 is a double-acting, single-rod ISO 15552 profile cylinder delivering 628 N of push force at 0.5 MPa and up to 879 N at 0.7 MPa. Its square extruded aluminum barrel eliminates external tie rods, yielding a compact, corrosion-resistant body that mounts flush against machine frames while exposing standardized ISO 15552 interface dimensions for universal hardware matching.
This 40 mm bore, 200 mm stroke unit features field-adjustable pneumatic cushioning at both ends (30 mm cushion length) to decelerate the 16 mm hard-chrome rod smoothly at high cycle rates. This SKU omits the built-in magnet, so it operates without position sensing unless an external switch is retrofitted.
| Model | Airtac SE40 Standard Cylinder SE40X200 |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø40 mm |
| Stroke | 200 mm |
| Acting type | Double acting |
| Port size | PT1/4 |
| Rod thread | M12×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 30 mm |
| Max stroke | Up to 1200 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 628 N | 528 N |
| 0.7 MPa | 880 N | — |
| Max (@1.0 MPa) | 128 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 40 | Bore size in mm. |
| ×200 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Drives the folding mechanism on packaging lines, utilizing the 628 N push force and 200 mm stroke to cleanly tuck cardboard flaps at high cycle rates.
Actuates routing flaps on a conveyor system, relying on the tie-rod-free extruded profile to mount flush within narrow transfer chute clearances.
Positions sheet metal backstops in a light-duty press brake, where the adjustable 30 mm end cushions absorb kinetic energy to prevent gauge bounce.
Choosing this 40 mm bore yields 628 N push at 0.5 MPa. If your load requires less force, stepping down to the 32 mm bore provides 402 N; if you need more power, scaling up to the 50 mm bore gives 982 N. For a 200 mm stroke, the 16 mm rod and M12x1.25 thread handle moderate side loads, but an external guide is recommended to prevent rod-bearing bending.
As a standard ISO 15552 cylinder, it is dimensionally interchangeable with other ISO 15552 profile cylinders, allowing you to reuse existing mounting hardware like FA front flanges or LB foot brackets. Remember that the adjustable air cushion only softens end-of-stroke impacts; it does not hold loads. If your process loses air, the piston will drift, requiring a BSE rod lock for secure positioning.
Quick checklist
At 0.5 MPa, the push force is 628 N and pull force is 528 N. At 0.7 MPa, push force is 879 N. The maximum push force is 128 kgf at 1.0 MPa, with an operating speed range of 30-800 mm/s.
Yes, the SE40X200 shares the exact ISO 15552 / VDMA 24562 mounting interface and PT1/4 port locations, making it a direct retrofit for other ISO 15552 profile cylinders using standard mounting accessories.
