Airtac SE40 Standard Cylinder SE40BX100S
The AirTAC SE40 Standard Cylinder SE40BX100S is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø40mm bore and 100mm stroke, PT1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ40 mm
- Stroke100 mm
- Port sizePT1/4
- Acting typeDouble acting
- Rod threadM12×1.25
- CushionAdjustable, 30 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SE40 Standard Cylinder SE40BX100S
The AirTAC SE40BX100S is a double-acting single-rod ISO 15552 profile cylinder engineered for demanding environments. It features a 40mm bore and a 100mm stroke, delivering 628 N of push force at 0.5 MPa and 879 N at 0.7 MPa. The extruded aluminum barrel omits external tie rods, yielding a compact, corrosion-resistant body that mounts flush against machine frames while leaving three sensor grooves fully exposed for rapid switch placement.
This specific configuration incorporates a SUS304 stainless steel rod (code B) for superior resistance to moisture and washdown chemicals, alongside a built-in magnet (code S) for position detection. The piston decelerates smoothly at both ends via a field-adjustable air cushion—simply turn the needle screw to tune the end-of-stroke damping for your specific load and speed. Operating at 30-800 mm/s, it uses a PT1/4 port and an M12x1.25 rod thread.
Airtac SE40 Standard Cylinder SE40BX100S Technical Specifications
| Model | Airtac SE40 Standard Cylinder SE40BX100S |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø40 mm |
| Stroke | 100 mm |
| Acting type | Double acting |
| Port size | PT1/4 |
| Rod thread | M12×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 30 mm |
| Max stroke | Up to 1200 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø40mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 628 N | 528 N |
| 0.7 MPa | 880 N | — |
| Max (@1.0 MPa) | 128 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE40 Standard Cylinder SE40BX100S
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 40 | Bore size in mm. |
| ×100 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE40 Standard Cylinder SE40BX100S Is Used
Flow Wrapper Film Sealing
Drives the end-sealing jaw on a horizontal flow wrapper, utilizing the 628 N push force and SUS304 rod to withstand frequent machine washdowns in food packaging facilities.
Bottle Divert Gate
Actuates a sorting diverter arm on a bottling line, where the 100mm stroke and 30-800 mm/s speed rapidly redirect containers without stalling the conveyor flow.
CNC Lathe Door Aperture
Opens and closes the safety interlock door on a CNC lathe, relying on the adjustable air cushion to soften the 100mm stroke impact and the no-tie-rod profile for a compact footprint.
Is the Airtac SE40 Standard Cylinder SE40BX100S the Right Cylinder?
When sizing this 40mm bore cylinder, evaluate your thrust margin: if 628 N push at 0.5 MPa is excessive for your payload, step down to the 32mm bore offering 402 N. If your mechanism demands more power, the 63mm bore provides 1559 N. Because this is a double-acting cylinder, it will drift if air supply is lost or a valve centers—the internal cushion only decelerates the stroke near the end caps and does not lock the load; use a BSE rod lock for positive holding. As a dimensionally interchangeable ISO 15552 cylinder, it serves as a direct retrofit for other 40mm bore profile cylinders, matching the PT1/4 port, 100mm stroke, and standard mounting footprint exactly.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE40 Standard Cylinder SE40BX100S FAQ
The 40mm bore generates 628 N push and 528 N pull at 0.5 MPa, 879 N push at 0.7 MPa, and a maximum of 128 kgf at 1.0 MPa. It operates at speeds of 30-800 mm/s.
Yes, the SE40BX100S is dimensionally interchangeable per ISO 15552 standards, matching the PT1/4 port, 16mm rod, and 100mm stroke dimensions. The built-in magnet also supports AirTAC CMSE reed and DMSE electronic sensors for position feedback.
