Airtac SE40 Standard Cylinder SE40BX140
The AirTAC SE40 Standard Cylinder SE40BX140 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø40mm bore and 140mm stroke, PT1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.
- BoreØ40 mm
- Stroke140 mm
- Port sizePT1/4
- Acting typeDouble acting
- Rod threadM12×1.25
- CushionAdjustable, 30 mm
- No minimum order. A single piece can be ordered.
- Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
About the Airtac SE40 Standard Cylinder SE40BX140
The AirTAC SE40BX140 is a double-acting single-rod ISO 15552 profile cylinder engineered for a 40 mm bore and a 140 mm stroke. It supplies a 628 N push force at 0.5 MPa, utilizing an extruded aluminum barrel that omits external tie rods for a flush, corrosion-resistant exterior that mounts cleanly in tight machinery.
This specific SKU is built with a SUS304 stainless steel rod (code B) for corrosive or washdown environments, and operates without a position sensor magnet. Field-adjustable pneumatic cushioning at both ends allows you to tune the end-of-stroke deceleration via a set screw, preventing hard mechanical impacts during high-speed cycling.
Airtac SE40 Standard Cylinder SE40BX140 Technical Specifications
| Model | Airtac SE40 Standard Cylinder SE40BX140 |
|---|---|
| Series | SE ISO 15552 profile cylinder |
| Bore size | Ø40 mm |
| Stroke | 140 mm |
| Acting type | Double acting |
| Port size | PT1/4 |
| Rod thread | M12×1.25 |
| Fluid | Air (filtered by 40µm element) |
|---|---|
| Operating pressure | 0.15 – 1.0 MPa |
| Proof pressure | 1.5 MPa |
| Temperature | -20 to +70 °C (0–150 °C with FKM seals) |
| Speed range | 30 – 800 mm/s |
| Cushion | Adjustable, 30 mm |
| Max stroke | Up to 1200 mm |
Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).
Theoretical Output Force (Ø40mm)
| Pressure | Push force | Pull force |
|---|---|---|
| 0.5 MPa | 628 N | 528 N |
| 0.7 MPa | 880 N | — |
| Max (@1.0 MPa) | 128 kgf | |
Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.
Model Code: Airtac SE40 Standard Cylinder SE40BX140
| SE | ISO 15552 / VDMA 24562 profile-barrel double-acting cylinder. |
|---|---|
| 40 | Bore size in mm. |
| ×140 | Stroke length in mm. |
| -S | Optional built-in magnet for CMSE / DMSE sensor sensing. |
Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).
Where the Airtac SE40 Standard Cylinder SE40BX140 Is Used
Flow Wrapper End-Seal Jaws
Drives the synchronous cutting and sealing jaws on continuous-motion horizontal flow wrappers, where the 628 N push force reliably overcomes packaging film resistance.
Lab Bottle Rinse Station
Lifts and lowers glass containers through a washdown rinse station, leveraging the SUS304 stainless steel rod to withstand constant moisture and mild cleaning chemicals.
PCB Panel Ejector
Pushes populated printed circuit boards out of an SMT testing fixture using a precise 140 mm stroke, relying on adjustable cushioning to protect delicate solder joints at end stops.
Is the Airtac SE40 Standard Cylinder SE40BX140 the Right Cylinder?
If your application requires less force, stepping down to the 32 mm bore yields a 402 N push at 0.5 MPa; conversely, moving up to the 50 mm bore provides a 982 N push. Because this SE40BX140 configuration lacks a position magnet, it cannot host CMSE or DMSE sensors—add the -S option if your control system requires end-of-stroke confirmation. As a standard ISO 15552 profile cylinder, it serves as a direct dimensional replacement for any equivalent ISO 15552 cylinder utilizing the same PT1/4 port and mounting accessories. Note that a plain double-acting cylinder drifts when air pressure is lost or exhausted; it cannot hold a load statically without live pressure, so specify a BSE rod lock variant if fail-safe holding is mandatory.
Quick checklist
- ✓ Required force at your working pressure
- ✓ Stroke and mounting space
- ✓ Port/thread type (PT/G)
- ✓ Magnet (-S) for CMSE/DMSE sensors?
- ✓ Side load — consider a guided cylinder
Installation & Maintenance Notes
- check Use clean air filtered to 40µm or finer.
- check Keep within 0.15 – 1.0 MPa operating pressure.
- check Avoid side load on the piston rod.
- check Adjust end cushion screws for smooth stops.
- check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
- check Installation by qualified personnel per AirTAC docs.
Airtac SE40 Standard Cylinder SE40BX140 FAQ
The SE40BX140 delivers a push force of 628 N and a pull force of 528 N at 0.5 MPa. At 0.7 MPa, the push force is 879 N, with a maximum push capacity of 128 kgf at 1.0 MPa. It features a 40 mm bore, 140 mm stroke, PT1/4 port, 16 mm rod, and operates at speeds of 30-800 mm/s.
Yes, the SE40BX140 is dimensionally interchangeable per ISO 15552 standards. Its square extruded profile barrel shares the exact same mounting interface and hole patterns as other ISO 15552 cylinders, allowing it to serve as a direct replacement using your existing mounting hardware and PT1/4 pneumatic fittings.
