AirTAC SE Series · ISO 15552 Cylinder

Airtac SE40 Standard Cylinder SE40X125

The AirTAC SE40 Standard Cylinder SE40X125 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø40mm bore and 125mm stroke, PT1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ40 mm
  • Stroke125 mm
  • Port sizePT1/4
  • Acting typeDouble acting
  • Rod threadM12×1.25
  • CushionAdjustable, 30 mm
$58.64 $66.14Save 11% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SE40 stroke, mounting and version on one page All SE40 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SE40 Standard Cylinder SE40X125

The AirTAC SE40X125 is a double-acting single-rod profile cylinder built to the ISO 15552 standard, delivering a push force of 628 N at 0.5 MPa. Its 125 mm stroke and 40 mm bore make it a versatile mid-range actuator for general automation. The square extruded aluminum barrel eliminates external tie rods, yielding a compact footprint that mounts flush to machine frames while resisting corrosion.

This model features field-adjustable air cushioning at both ends, allowing technicians to tune end-of-stroke deceleration and soften hard impacts at operating speeds up to 30-800 mm/s. It uses a PT1/4 port and a 16 mm hard-chrome plated rod. Note that this specific SKU is configured without a sensor magnet, so it does not directly support CMSE or DMSE electronic position switches without modification.

Airtac SE40 Standard Cylinder SE40X125 Technical Specifications

ModelAirtac SE40 Standard Cylinder SE40X125
SeriesSE ISO 15552 profile cylinder
Bore sizeØ40 mm
Stroke125 mm
Acting typeDouble acting
Port sizePT1/4
Rod threadM12×1.25
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 30 mm
Max strokeUp to 1200 mm

Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø40mm)

PressurePush forcePull force
0.5 MPa628 N528 N
0.7 MPa880 N—
Max (@1.0 MPa)128 kgf

Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SE40 Standard Cylinder SE40X125

SEISO 15552 / VDMA 24562 profile-barrel double-acting cylinder.
40Bore size in mm.
×125Stroke length in mm.
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).

Where the Airtac SE40 Standard Cylinder SE40X125 Is Used

packaging

Carton Flap Folding

Provides the precise 628 N push and 125 mm travel needed to fold corrugated cardboard flaps on high-speed packaging lines before taping.

conveyor_belt

Sorter Diverter Gate

Actuates routing gates on parcel conveyor systems, using its 125 mm stroke to redirect packages efficiently without occupying excessive frame space.

view_module

PCB Test Fixture

Drives electronic test probes down onto printed circuit boards, where the compact tie-rod-free profile allows dense mounting in testing arrays.

Is the Airtac SE40 Standard Cylinder SE40X125 the Right Cylinder?

Choosing this 40 mm bore makes sense when your application requires the 628 N push force at 0.5 MPa. If you need less force and a smaller footprint, the neighbouring 32 mm bore provides 402 N of push. Conversely, stepping up to the 50 mm bore yields 982 N for heavier payloads. Because this is a standard 125 mm stroke within a profile body, it serves as a direct dimensional replacement for any ISO 15552 cylinder with matching travel and PT1/4 ports.

Remember that the adjustable air cushion only decelerates the piston near the stroke ends; it is not a locking mechanism. If your process must hold a vertical load without constant air pressure, you must integrate an external pilot-operated check valve or step over to the BSE rod-lock variant. Furthermore, since this SKU lacks the -S magnet, you cannot track piston position without adding external sensors.

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SE40 Standard Cylinder SE40X125 FAQ

The SE40X125 generates 628 N of push force and 528 N of pull force at 0.5 MPa. At 0.7 MPa, the push force increases to 879 N. The maximum push force is 128 kgf at 1.0 MPa. This 40 mm bore cylinder features a PT1/4 port and a 16 mm rod.

Yes, the SE40X125 is dimensionally interchangeable per ISO 15552 standards. You can use it as a direct replacement for other ISO 15552 profile cylinders with a 40 mm bore and 125 mm stroke, utilizing standard mounting accessories like FA or LB brackets.
