AirTAC SE Series · ISO 15552 Cylinder

Airtac SE40 Standard Cylinder SE40X160

The AirTAC SE40 Standard Cylinder SE40X160 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø40mm bore and 160mm stroke, PT1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ40 mm
  • Stroke160 mm
  • Port sizePT1/4
  • Acting typeDouble acting
  • Rod threadM12×1.25
  • CushionAdjustable, 30 mm
$62.77 $70.27Save 10% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SE40 stroke, mounting and version on one page All SE40 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SE40 Standard Cylinder SE40X160

The AirTAC SE40X160 is a double-acting single-rod ISO 15552 profile cylinder engineered to deliver 628 N of push force and 528 N of pull force at 0.5 MPa. Driven by a 16 mm hard-chrome rod with an M12x1.25 end thread, it provides robust actuation for mid-range automation tasks.

Built with an extruded aluminum square barrel, this unit eliminates external tie rods to provide a flush, corrosion-resistant body that mounts cleanly in tight spaces. The field-adjustable pneumatic cushioning at both ends allows you to tune the end-of-stroke deceleration via a set screw, ensuring smooth stops even at the maximum operating speed of 30-800 mm/s. Note that this specific SKU lacks a built-in magnet, so it does not directly support CMSE or DMSE position sensing.

Airtac SE40 Standard Cylinder SE40X160 Technical Specifications

ModelAirtac SE40 Standard Cylinder SE40X160
SeriesSE ISO 15552 profile cylinder
Bore sizeØ40 mm
Stroke160 mm
Acting typeDouble acting
Port sizePT1/4
Rod threadM12×1.25
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 30 mm
Max strokeUp to 1200 mm

Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø40mm)

PressurePush forcePull force
0.5 MPa628 N528 N
0.7 MPa880 N—
Max (@1.0 MPa)128 kgf

Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SE40 Standard Cylinder SE40X160

SEISO 15552 / VDMA 24562 profile-barrel double-acting cylinder.
40Bore size in mm.
×160Stroke length in mm.
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).

Where the Airtac SE40 Standard Cylinder SE40X160 Is Used

conveyor_belt

Package Routing Diverter

Uses the 160 mm stroke to push cardboard cartons cleanly between sorting lanes on a packaging conveyor, relying on the 628 N push force to handle boxes up to 60 kg without bouncing.

precision_manufacturing

CNC Fixture Clamping

Secures aluminum engine housings inside a machining center, utilizing the 528 N pull force to hold the part firmly against the fixture wall during light milling operations.

packaging

Pallet Film Wrap Arm

Actuates a film carriage cutting and tamping head on a stretch wrapper, where the 30 mm adjustable cushion length ensures the blade assembly does not slam into the pallet base at high cycle speeds.

Is the Airtac SE40 Standard Cylinder SE40X160 the Right Cylinder?

Selecting this 40 mm bore is ideal when you need 628 N of thrust at 0.5 MPa but want to avoid the bulk of a 50 mm cylinder (which provides 982 N). If your payload is lighter, stepping down to a 32 mm bore yields 402 N of push force in a more compact footprint. Because this model features a 160 mm stroke, you should support the load with an external guide to prevent rod-bearing bending under side loads. As a standard ISO 15552 profile cylinder, it serves as a direct replacement for any ISO 15552 cylinder of the same bore and stroke, utilizing standard PT1/4 ports and interchangeable mounting accessories. Remember that the adjustable air cushion only decelerates the piston near stroke end; it is not a locking device, so a BSE rod lock is required to hold a load safely without live air pressure.

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SE40 Standard Cylinder SE40X160 FAQ

The SE40X160 features a 40 mm bore and a PT1/4 port. At 0.5 MPa it provides 628 N of push force and 528 N of pull force. At 0.7 MPa the push force is 879 N, and the maximum push force is 128 kgf at 1.0 MPa.

Yes. It is a true ISO 15552 profile cylinder, making it dimensionally interchangeable with other ISO 15552 cylinders of the same 40 mm bore and 160 mm stroke. You can reuse your existing mounting hardware and accessories without redrilling.
