AirTAC SE Series · ISO 15552 Cylinder

Airtac SE40 Standard Cylinder SE40X250

The AirTAC SE40 Standard Cylinder SE40X250 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø40mm bore and 250mm stroke, PT1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ40 mm
  • Stroke250 mm
  • Port sizePT1/4
  • Acting typeDouble acting
  • Rod threadM12×1.25
  • CushionAdjustable, 30 mm
$70.01 $77.51Save 9% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SE40 stroke, mounting and version on one page All SE40 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SE40 Standard Cylinder SE40X250

The AirTAC SE40X250 is a double-acting, single-rod ISO 15552 profile cylinder delivering 628 N of push force at 0.5 MPa. Its square extruded aluminum barrel removes the need for external tie rods, yielding a compact, corrosion-resistant body that mounts flush against machine frames. This clean profile also integrates sensor grooves on three sides, though this specific SKU omits the -S magnet and therefore does not support CMSE or DMSE position sensing without modification.

Field-adjustable pneumatic cushioning at both ends allows you to tune end-of-stroke deceleration via a set screw, softening hard impacts when cycling at speeds up to 800 mm/s. The 250 mm stroke is driven by a 16 mm rod with an M12x1.25 thread, utilizing a PT1/4 port. Because the cushion only decelerates the piston near stroke end, it cannot hold a load if air pressure drops.

Airtac SE40 Standard Cylinder SE40X250 Technical Specifications

ModelAirtac SE40 Standard Cylinder SE40X250
SeriesSE ISO 15552 profile cylinder
Bore sizeØ40 mm
Stroke250 mm
Acting typeDouble acting
Port sizePT1/4
Rod threadM12×1.25
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 30 mm
Max strokeUp to 1200 mm

Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø40mm)

PressurePush forcePull force
0.5 MPa628 N528 N
0.7 MPa880 N—
Max (@1.0 MPa)128 kgf

Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SE40 Standard Cylinder SE40X250

SEISO 15552 / VDMA 24562 profile-barrel double-acting cylinder.
40Bore size in mm.
×250Stroke length in mm.
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).

Where the Airtac SE40 Standard Cylinder SE40X250 Is Used

conveyor_belt

Package Diverter Arm

Actuates a routing gate on a 24V DC conveyor line, using the 628 N push force to reliably pivot heavy cardboard cartons into a packing lane.

packaging

Case Erector Jaws

Drives the folding mechanism on a vertical case erector, where the 250 mm stroke provides the exact travel needed to fold major box flaps.

science

Lab Sample Dispenser

Pushes sample trays into a testing instrument, benefiting from the adjustable end cushions to prevent liquid spillage during rapid 30-800 mm/s transfers.

Is the Airtac SE40 Standard Cylinder SE40X250 the Right Cylinder?

With a 628 N push at 0.5 MPa, this 40 mm bore sits neatly between the 32 mm (402 N) and 50 mm (982 N) bores, letting you step down for lighter fixtures or up for heavier payloads. As a dimensionally interchangeable ISO 15552 cylinder, it serves as a direct replacement for other standard profile cylinders, matching the 40 mm bore, 250 mm stroke, PT1/4 port, and standard mounting accessories. At 250 mm of travel, the unsupported piston rod is susceptible to bending under lateral stress; for offset loads, incorporate an external guide bearing to prevent rod-bearing wear. Remember that a plain SE cylinder drifts if air is lost—use a BSE rod lock if the application requires fail-safe position holding.

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SE40 Standard Cylinder SE40X250 FAQ

The SE40X250 generates 628 N of push force and 528 N of pull force at 0.5 MPa. At 0.7 MPa, the push force is 879 N. The maximum push force is 128 kgf at 1.0 MPa.

No. The adjustable air cushions at both ends only decelerate the piston near the stroke ends; they do not act as a brake. If air is exhausted or pressure drops, the cylinder will drift. For fail-safe load holding, use a BSE series rod lock cylinder or an external pilot-operated check valve.
