AirTAC SE Series · ISO 15552 Cylinder

Airtac SE40 Standard Cylinder SE40X300

The AirTAC SE40 Standard Cylinder SE40X300 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø40mm bore and 300mm stroke, PT1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ40 mm
  • Stroke300 mm
  • Port sizePT1/4
  • Acting typeDouble acting
  • Rod threadM12×1.25
  • CushionAdjustable, 30 mm
$74.66 $82.16Save 9% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SE40 stroke, mounting and version on one page All SE40 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SE40 Standard Cylinder SE40X300

The AirTAC SE40X300 is a double-acting single-rod ISO 15552 profile cylinder engineered to deliver 628 N of push force and 528 N of pull force at 0.5 MPa. With a 40 mm bore and 300 mm stroke, it operates efficiently at speeds between 30 and 800 mm/s using a PT1/4 port. The square extruded aluminum barrel omits external tie rods, yielding a smooth, compact body that resists corrosion and mounts flush against machine frames, simplifying spatial constraints in tight assemblies.

This model features field-adjustable pneumatic cushioning at both ends, allowing technicians to tune the end-of-stroke deceleration via a set screw to prevent hard mechanical impacts during high-speed cycling. Note that this specific SKU is configured without a built-in magnet, meaning it is not equipped for AirTAC CMSE or DMSE position sensing out of the box. The standard PT1/4 tapered port and M12x1.25 rod-end thread ensure straightforward integration into existing pneumatic infrastructures.

Airtac SE40 Standard Cylinder SE40X300 Technical Specifications

ModelAirtac SE40 Standard Cylinder SE40X300
SeriesSE ISO 15552 profile cylinder
Bore sizeØ40 mm
Stroke300 mm
Acting typeDouble acting
Port sizePT1/4
Rod threadM12×1.25
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 30 mm
Max strokeUp to 1200 mm

Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø40mm)

PressurePush forcePull force
0.5 MPa628 N528 N
0.7 MPa880 N—
Max (@1.0 MPa)128 kgf

Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SE40 Standard Cylinder SE40X300

SEISO 15552 / VDMA 24562 profile-barrel double-acting cylinder.
40Bore size in mm.
×300Stroke length in mm.
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).

Where the Airtac SE40 Standard Cylinder SE40X300 Is Used

packaging

Carton Erector Arms

Drives the folding mechanisms on continuous-motion packaging lines, using the 300 mm stroke to open and erect corrugated carton blanks with 628 N of thrust.

conveyor_belt

Pallet Diverters

Actuates routing gates along flat-belt conveyors, leveraging the smooth extruded profile to mount flush within the frame and push intermediate goods smoothly.

science

Lab Sample Handlers

Positions analytical test tubes in automated diagnostic machinery, relying on the field-adjustable cushioning to ensure gentle, vibration-free stops at the end of the 300 mm extension.

Is the Airtac SE40 Standard Cylinder SE40X300 the Right Cylinder?

When sizing this 40 mm bore model, which generates 628 N of push at 0.5 MPa, consider stepping down to the 32 mm bore (402 N push) for lighter loads or stepping up to the 50 mm bore (982 N push) for heavier thrust requirements. Because this unit features a 300 mm stroke, the extended unsupported rod length increases the risk of side-load bending at the front bearing; utilizing an external guide mechanism is strongly recommended to prevent premature seal wear and rod deflection. Furthermore, if the application requires the load to be physically held in place during air loss or valve centering, note that the standard SE cylinder lacks a locking mechanism—explore the AirTAC BSE series for an integrated rod lock solution. As a true ISO 15552 profile cylinder, it serves as a direct dimensional replacement for any compliant ISO 15552 unit, sharing standardized mounting hardware like FA front flanges or LB foot brackets.

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SE40 Standard Cylinder SE40X300 FAQ

The SE40X300 generates 628 N push and 528 N pull at 0.5 MPa, 879 N push at 0.7 MPa, and a maximum of 128 kgf at 1.0 MPa. It operates at pressures from 0.15-1.0 MPa with a speed range of 30-800 mm/s.

Yes, the SE40X300 is dimensionally interchangeable per ISO 15552 standards, meaning it matches the standardized mounting footprint and shares hardware with other ISO 15552 profile cylinders. The adjustable air cushion at both ends can also be fine-tuned to match your existing machine's cycle dynamics.
