AirTAC SE Series · ISO 15552 Cylinder

Airtac SE40 Standard Cylinder SE40X75

The AirTAC SE40 Standard Cylinder SE40X75 is a genuine double-acting ISO 15552 / VDMA 24562 profile-barrel air cylinder with a Ø40mm bore and 75mm stroke, PT1/4 air ports and adjustable end cushioning. Its standardized mounting interface makes it interchangeable with other ISO 15552 cylinders at the mounting interface.

  • BoreØ40 mm
  • Stroke75 mm
  • Port sizePT1/4
  • Acting typeDouble acting
  • Rod threadM12×1.25
  • CushionAdjustable, 30 mm
$54.50 $62.00Save 12% Standard model — ready in 3-5 business days to process and dispatch
Request a Quote
  • No minimum order. A single piece can be ordered.
  • Ready in 3–5 business days. That is the time we take to process the order and hand it to the carrier. Transit time after that depends on the destination.
Compare every SE40 stroke, mounting and version on one page All SE40 codes →
verified Genuine AirTAC workspace_premium 1-year warranty bolt Reply in 7-8 h

About the Airtac SE40 Standard Cylinder SE40X75

The AirTAC SE40X75 is a double-acting single-rod ISO 15552 profile cylinder delivering 628 N push and 528 N pull at 0.5 MPa. Its extruded aluminum square barrel omits external tie rods, yielding a compact, flush-mounting body that resists corrosion and simplifies sensor placement along three integrated grooves.

This 40 mm bore unit operates at speeds of 30-800 mm/s and features field-adjustable pneumatic cushioning at both ends. The cushion screws let technicians fine-tune end-of-stroke deceleration to eliminate hard mechanical impacts. This specific SKU lacks a built-in magnet, so it ships without position sensing unless external switches are retrofitted.

Airtac SE40 Standard Cylinder SE40X75 Technical Specifications

ModelAirtac SE40 Standard Cylinder SE40X75
SeriesSE ISO 15552 profile cylinder
Bore sizeØ40 mm
Stroke75 mm
Acting typeDouble acting
Port sizePT1/4
Rod threadM12×1.25
FluidAir (filtered by 40µm element)
Operating pressure0.15 – 1.0 MPa
Proof pressure1.5 MPa
Temperature-20 to +70 °C (0–150 °C with FKM seals)
Speed range30 – 800 mm/s
CushionAdjustable, 30 mm
Max strokeUp to 1200 mm

Specifications follow the official AirTAC SE series datasheet and ISO 15552 / VDMA 24562 dimensions. Confirm against the product label before installation. Port options: PT (standard) / G (BSPP).

Theoretical Output Force (Ø40mm)

PressurePush forcePull force
0.5 MPa628 N528 N
0.7 MPa880 N—
Max (@1.0 MPa)128 kgf

Actual usable force is lower than theoretical due to friction and back-pressure. Size with a safety margin.

Model Code: Airtac SE40 Standard Cylinder SE40X75

SEISO 15552 / VDMA 24562 profile-barrel double-acting cylinder.
40Bore size in mm.
×75Stroke length in mm.
-SOptional built-in magnet for CMSE / DMSE sensor sensing.

Rod material: carbon steel (blank) / SUS420J2 (A) / SUS304 (B). Seals: TPU (blank) / FKM high-temp (H) / NBR (N). Thread: PT (blank) / G. Mounting: Basic, LB, FA, FB, CA, CB, CR, TC, FTC, TCM1, TCM2. Related SE-family variants: SED (double rod), SEJ (adjustable stroke), BSE (rod lock), BSED (double-rod rod lock).

Where the Airtac SE40 Standard Cylinder SE40X75 Is Used

precision_manufacturing

CNC Fixture Clamping

Secures aluminum workpieces in machining centers using 628 N of extend force at 0.5 MPa, ensuring zero part shift during high-speed milling.

packaging

Carton Flap Folding

Drives folding arms on continuous packaging lines at up to 800 mm/s, utilizing the 75 mm stroke to tuck corrugated flaps before sealing.

conveyor_belt

Sorter Diverter Gate

Pivots routing gates on package conveyors, relying on the adjustable pneumatic cushion to soften directional changes without mechanical shock.

Is the Airtac SE40 Standard Cylinder SE40X75 the Right Cylinder?

When sizing this 75 mm stroke unit, compare its 628 N push at 0.5 MPa against the smaller 32 mm bore (402 N push) for lighter duties, or step up to the 50 mm bore (982 N push) for heavier loads. Because this is a standard double-acting cylinder, it cannot hold a load if air pressure drops or the valve centers; the piston will drift. For position-holding safety, consider the BSE rod-lock variant. To replace an existing cylinder, match the 40 mm bore, 75 mm stroke, PT1/4 port, and mounting accessory. Strokes under 300 mm generally do not require external side-load guides, but always verify rod-bearing bending if pushing off-center loads.

Quick checklist

  • ✓ Required force at your working pressure
  • ✓ Stroke and mounting space
  • ✓ Port/thread type (PT/G)
  • ✓ Magnet (-S) for CMSE/DMSE sensors?
  • ✓ Side load — consider a guided cylinder
Ask an Engineer

Installation & Maintenance Notes

  • check Use clean air filtered to 40µm or finer.
  • check Keep within 0.15 – 1.0 MPa operating pressure.
  • check Avoid side load on the piston rod.
  • check Adjust end cushion screws for smooth stops.
  • check Use correct mounting accessory (LB/FA/FB/CA/CB/CR/TC/FTC/TCM1/TCM2).
  • check Installation by qualified personnel per AirTAC docs.

Airtac SE40 Standard Cylinder SE40X75 FAQ

At 0.5 MPa, the SE40X75 generates 628 N of push force and 528 N of pull force. At 0.7 MPa, the push force increases to 879 N. The maximum push force is 128 kgf when operating at the maximum rated pressure of 1.0 MPa.

Yes, the SE40X75 is a true ISO 15552 / VDMA 24562 profile cylinder. Its standardized mounting dimensions and PT1/4 port allow it to serve as a direct replacement for other ISO 15552 profile cylinders, sharing identical mounting hardware and footprint without external tie rods.
